DCA300SSC GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (06/25/09) — PAGE 57
NO. PART NO. PART NAME QTY. REMARKS
1 C2110000002 ROTOR ASSY ..........................................1 ............. INCLUDES ITEMS W/#
1-1# FIELD ASSY 1
1-2# 0601842402 RESISTOR, 80W 300K 2
1-3# 0601823282 RECTIFIER 1
1-4# 0018205020 HEX HD. CAP SCREW 2
1-4A# 0040005000 WASHER, LOCK 2
1-4B# 0041205000 WASHER, FLAT 2
1-5# 8201070002 FAN 1
1-6# 8201611004 COUPLING DISK 12
1-7# C3164200004 WASHER, COUPLING HUB 1
1-8# 8201015003 BALANCING PLATE .................................1 ............. PURCHASE ITEM 1-11 AS A SET
1-9# 0012116045 HEX HEAD BOLT 10
1-10# 0042616000 WASHER, LOCK 10
1-11# 0601000209 BALANCING WEIGHT KIT 1
1-12# C3112500004 BEARING FLANGE 1
1-13# 0071906315 BEARING 1
2 C2163400003 COUPLING RING 1
3 0343206200 HEX HEAD BOLT 8
4 0043606000 WASHER, LOCK 8
5# 0010312040 HEX HEAD BOLT 12
5A# 0042512000 WASHER, LOCK 12
6 C2130100103 STATOR ASSY 1
6-1 0226200430 RUBBER SEAL 1
6-2 8201323004 CLAMPER 1
6-3 0223300140 RUBBER SEAL 1
6-4 8201323103 CLAMPER 1
6-5 0221200350 RUBBER SEAL 1
6-6 0010110035 HEX HEAD BOLT 2
6-6A 0041210000 WASHER, FLAT 2
6-7 C2132200003 COVER 1
6-8 0226000275 RUBBER SEAL 2
6-9 0225000500 RUBBER SEAL 1
6-10 0017106016 HEX HEAD BOLT 6
6-11 0601850144 GROMMET 1
7 C3154000002 END BRACKET 1
8 C3138000003 FIELD ASSY, EXCITER 1
9 0012110080 HEX HEAD BOLT 4
9 A 0042610000 WASHER, LOCK 4
9 B 0041210000 WASHER, FLAT 4
10 0017112045 HEX HEAD BOLT 8
11 C3154300104 COVER, BEARING 1
12 C3154300004 GASKET, BEARING 1
13 0010106060 HEX HEAD BOLT 4
13A 0040006000 WASHER, LOCK 4
13B 0041206000 WASHER, FLAT 4
GENERATOR ASSY.
