PAGE 79 — DCA-25SSIU — PARTS AND OPERATION MANUAL (STD) — REV. #7 (04/18/12)
NO. PART NO. ITEM QTY. REMARKS
ENCLOSURE ASSY.
DCA-25SSIU --- ENCLOSURE ASSY.
1 M1413000212 BASE ................................................... 1 ............. S/N7100291 TO S/N7104749
REPLACES M1413000202
M1413000222 BASE ................................................... 1 ............. S/N7104750~
2 M1413400004 UNDER COVER 1
3 011008020 HEX. HEAD BOLT ............................... 2 .............REPLACES 0016908020
4 M1423000302 FRONT FRAME .................................. 1 ............. S/N7100001 TO 7105049
M1493100503 ACOUSTIC SHEET ............................ 1 .............S/N7100001 TO 7105049
M1423000312 FRONT FRAME .................................. 1 ............. S/N7105050~
M1493100513 ACOUSTIC SHEET ............................ 1 .............S/N7105050~
5 011008020 HEX.HEAD BOLT ................................ 4 .............REPLACES 0016908020
6 M1423200304 COVER, FRONT FRAME 1
M1493100604 ACOUSTIC SHEET 1
7 011008020 HEX HEAD BOLT .............................. 11 .............REPLACES 0016908020
8 M1433000203 CENTER FRAME 1
9 M1433000303 CENTER FRAME 1
10 0010114030 HEX. HEAD BOLT 8
030214350 LOCK WASHER .................................. 8 .............REPLACES 0040014000
031114260 PLAIN WASHER.................................. 8 .............REPLACES 0041214000
11 M1443000502 REAR FRAME 1
12 011008020 HEX. HEAD BOLT ............................... 4 .............REPLACES 0016908020
0040508000 TOOTHED WASHER 1
13 M1443300513 REAR COVER ..................................... 1 .............REPLACES M1443300503
M1493300304 ACOUSTIC SHEET 1
14 M1443300403 DUCT, REAR COVER 1
M1493300404 ACOUSTIC SHEET 1
15 0207006000 HEX. NUT 7
16 011008020 HEX. HEAD BOLT ............................... 6 .............S/N7100001 TO S/N7100290;
REPLACES 0016908020
011008020 HEX. HEAD BOLT ............................... 7 .............S/N7100291~; REPLACES 0016908020
17 M1443200613 REAR DOOR ...................................... 1 .............REPLACES M1443200603
18 M1443600004 WINDOW PLATE ................................ 1 .............S/N7100001 TO S/N7100725
M1443600104 WINDOW PLATE ................................ 1 .............S/N7100726 TO S/N7101589
M1443600114 WINDOW PLATE ................................ 1 .............S/N7101590~
19 020106050 HEX. NUT ............................................ 6 .............S/N7100001 TO S/N7101449;
REPLACES 0037906000
0027306000 HEX. NUT ............................................ 6 .............S/N7101450 TO S/N7101589
0207306000 HEX. NUT ............................................ 8 .............
S/N7101590~
952404470 PLAIN WASHER................................ 12 ............. S/N7100001 TO S/N7101449;
REPLACES 0041206000
952404470 PLAIN WASHER.................................. 6 .............S/N7101450 TO S/N7101589;
REPLACES 0041206000
952404470 PLAIN WASHER.................................. 8 .............S/N7101590~; REPLACES 0041206000
20 M911300002 DOOR HANDLE ASSY. 1
21 0021706015 MACHINE SCREW 4
020106050 HEX. NUT ............................................ 4 .............REPLACES 0030006000
