Section 1: Assembly and Set-up
FM2060 & FM2072 Flail Mowers 309-100M
3/25/08
Land Pride
Table of Contents
Section 1: Assembly and Set-up
Tractor Requirements
This mower is designed with a 3-Point category I hitch.
Horse power rating of tractor should not exceed 40 PTO
horse power for the Flail Mowers.
NOTE: In order to maintain steering control, ballast
may need to be added to your tractor. To determine
whether or not to add the ballast, refer to your
tractor’s operator manual.
Hitch Assembly
Refer to Figure 1-1:
4. The hitch is disassembled for ease in shipping.
5. Assemble the hitch (#1) to the flail mower and secure
with the bolts (#2), lock washers (#3) and nuts (#4)
as shown.
6. The hitch can be assembled in two different
positions; (#5) and (#6) for either a left offset or right
offset.
7. Tighten all hardware.
Hitch Assembly
Figure 1-1
17966
