Item
No.
Part Name Q’TY
1 CLEANER COVER 1
2 CLEANER ELEMENT (B) 1
3 CLEANER ELEMENT (A) 1
4 CLEANER ELEMENT ASS'Y 1
5 COVER SET BOLT 3
6 ALUMINUM TAPE (A) 1
7 CYLINDER COVER 1
8 CLEANER KNOB 1
9 SHUTTER PLATE 1
10 MACHINE SCREW M4 × 10 6
11 SCAVENGING COVER (B) 1
12 COVER PACKING 2
13 SPARK PLUG BPMR7A 1
14 INTAKE PACKING 1
15 INTAKE 1
16 HEX. SOCKET HD. BOLT M5 × 12 2
17 ALUMINUM TAPE (B) 1
18 CARBURETOR INSULATOR 1
19 CARB. INSULATOR RUBBER 1
20 CARBURETOR ASS'Y 1
21 SET SCREW 1
22 PUMP
BODY 1
23 PUMP GASKET 1
24 PUMP DIAPHRAGM 1
25 INLET SCREEN 1
26 NEEDLE VALVE 1
27 VALVE SPRING 1
28 DIAPHRAGM PACKING 1
29 METERING DIAPHRAGM COMP. 1
30 DIAPHRAGM COVER 1
31 IDLE ADJUST SPRING 1
32 IDLE ADJUST SCREW 1
33 HINGE PIN SET SCREW 1
34 CONTROL LEVER 1
35 HINGE PIN 1
36 SET SCREW 4
37 IDLE SPONGE 1
38 D6 CLIP 3
39 TAPPING SCREW (W/FLANGE) D5 × 20 4
40 CLEANER SUPPORT 1
41 WASHER D5 7
42 HEX. SOCKET HD. BOLT M5 × 45 2
43 FUEL PIPE 1
44 SCAVENGING COVER (A) 1
45 WASHER 2
46 PLUG CAP 1
47 CORD (A) 1
48 METAL FITTING OF PLUG CAP 1
49 CORD (B) 1
50 IGNITION COIL ASS'Y 1
51 SEAL LOCK HEX. SOCKET FLANGE BOLT M4 2
52 CODE INSULATION TUBE 1
53 HEX. SOCKET BOLT (SUS) M4 3
54 MUFFLER PROTECTOR 1
55 MUFFLER PROTECTOR PACKING 1
56 MUFFLER GAUZE 1
57 EXHAUST PLATE 1
58 FLANGE NUT M6 2
59 MUFFLER 1
60 HEX SOCKET HD. BOLT (W/S.WASHER) M5 1
61 MUFFLER PACKING 1
62 SQUARE HEAD BOLT M6 2
63 CYLINDER SUPPLY ASS'Y 1
64 CYLINDER PACKING 1
65 PISTON RING 2
66 CIR CLIP 2
67 PISTON (M) 1
68 PISTON PIN 1
69 CRANK CASE ASS'Y 1
Item
No.
Part Name Q’TY
70 OIL SEAL TB 12227 2
71 BALL BEARING 2
72 PISTON PIN COLLAR 2
73 NEEDLE BEARING (A) 1
74 CRANK CASE PACKING 1
75 SPRING LOCK WASHER D5 4
76 SEAL LOCK HEX. SOCKET HD. BOLT M5 4
77 CRANK SHAFT 1
78 SHIM 1
79
HEX. SOCKET HD. BOLT (W/SP.WASHER)
M5 × 20
8
80 MAGNETO SUB ASS'Y 1
81 MAGNETO ROTOR 1
82 STARTER PAWL SPRING 2
83 WASHER 0.8 2
84 STARTER PAWL 2
85 STEP BOLT 2
86 BOLT WASHER D7 1
87 FLYWHEEL
NUT 1
88 SPIKE SET 1
89 ALUMINIUM TAPE 1
90 ENGINE CASE 1
91 CHOKE ROD RUBBER 1
92 CHOKE BUTTON 1
93 STOP SWITCH 1
94 PRIMING PUMP COMP. 1
95 REAR DAMPER 1
96 AIR VENT VALVE (B) 1
97 AIR VENT SPONGE 1
98 TANK CAP PACKING 2
99 TANK CAP ASS'Y 2
111 NUT M6 3
112 BOLT WASHER D6 3
113 SPRING HOLDER 2
114 FLANGED TAPPING SCREW D6 2
115 ANTIVIBRATION SPRING 2
116 FRONT DAMPER 1
117 PUMP FILTER BODY ASS'Y 1
118 RETURN GROMMET 1
119 FUEL PIPE (PINK) 1
120 INNER CAP ASS'Y 1
121 THROTTLE ROD 1
122 THROTTLE LEVER 1
123 FUEL GROMMET (A) 1
124 FUEL PIPE 1
125 TAPPING SCREW (W/FLANGE) D4 × 16 8
126 REAR HANDLE GRIP 1
127 TRIGGER LOCKOUT 1
128 THROTTLE LEVER SPRING 1
129 SPRING PIN D5 × 25 1
130 REAR HANDLE 1
131 SPRING HOLDER 1
132
HEX. SOCKET HD. BOLT (W/FLANGE)
M6 × 20
1
133 ANTIVIBRATION SPRING 1
134 TAPPING SCREW (W/FLANGE) D5 × 25 4
135 BRAKE LINK COVER 1
136 BRAKE LINK ASS'Y 1
137 RETAINING RING (E-TYPE) FOR D6 SHAFT 1
138 BRAKE
SPRING 1
139 NEEDLE ROLLER D3 1
140 BRAKE BAND PLATE 1
141 TAPPING SCREW (W/FLANGE) D4 × 10 1
142 FRONT HANDLE 1
143 OIL PUMP COVER 1
144 OIL PIPE 1
145 OIL PUMP 1
146 BRAKE LEVER SPRING 1
147 CAUTION LABEL 1
