Page 4SKU 09712
Parts List and Assembly Drawing
Part No. Description Qty Part No. Description Qty
1 Base 1 15 Nylon Nut 1
2 Pruner Blade 1 16 Screw 1
3 Pole Socket 1 17 Washer 2
4 Pulling Base 1 18 Nylon Nut 1
5 Saw Blade 1 19 Mounting Bolt 1
6 Pulley Base (A) 1 20 Wing Nut 1
7 Pulley Base (B) 1 21 Screw 2
8 Pulley 2 22 Nut 2
9 Grip 1 23 Bolt 2
10 Lock Ring 1 24 Bolt 1
11 Spring 1 25 Bolt 1
12 Center Screw 1 26 Bolt 2
13 Spring Washer 1 27 Bolt 2
14 Washer 1
