four mower mounting holes.
(See Figure A.)
NOTE: Depending on the mower, it may
be necessary to drill mounting holes or
make a mounting plate to align with the
engine mounting holes.
Use four 3/8” diameter, coarse threaded, 4.
hardened, stainless steel Bolts, Lock
Washers, and Washers (not included) of
appropriate length to secure the Engine
to the mower.
Make sure the hardware does not
contact moving parts.
FIGURE B
Choke
Control
Automatic
Throttle Control
(NOT ADJUSTABLE)
Choke
bracket
mower choke
cable sheath
mower
choke
cable
5. Insert the mower’s choke cable sheath
through the hole in the Choke bracket.
Secure the mower choke cable to the
choke control. Adjust the choke cable
sheath to remove all slack and secure it
in place using the adjusting nuts on the
cable sheath. (See Figure B.)
FIGURE C
Brake
bracket
Brake
arm
mower brake
cable sheath
mower brake
cable
6. Insert the mower’s brake cable sheath
through the hole in the Brake bracket.
Secure the mower brake cable to the
brake arm. Adjust the brake cable
sheath to remove all slack and secure it
in place using the adjusting nuts on the
cable sheath. (See Figure C.)
THE ENGINE BRAKE IS FOR
EMERGENCY SHUTOFF; DO NOT
REPLACE THE BRAKE SPRING WITH
A WEAKER SPRING. If operating
the engine brake is too difcult, a
qualied technician must install a
different brake handle on the mower.
Note: The brake/choke cables on some
mowers may need to be adjusted in a
different manner. Install according to
mower manufacturer’s instructions.
Throttle Control7. - The throttle control on
this engine is controlled automatically.
Only a qualied technician should
adjust the throttle controlling
mechanism.
Refer to the mower’s service manual for 8.
instructions on how to properly attach a
belt drive pulley, chain drive gear, etc.
onto the output shaft of the Engine.
