SKU 95845
For technical questions, please call 1-800-444-3353
ASSEMBLY
We suggest you assemble the unit on a soft surface to avoid damage to the finish.
Attach the five wooden Seat Slats (3) onto the right and left Arm Rests (1) using the
Screws (9) on the top side of the Slats and the Washers (8) and Nuts (10) on the
underside. Hand tighten. See Figure 1.
5
7 & 8
FIGURE 2
3
Attach the Seat Brace (5) to the wooden Seat Slats (3) using the Tap Screws (7).
Tighten all hardware after assembly. See Figure 2.
Note: It may become necessary to enlarge the holes in the Seat Slats (3). Clear the hole of
paint or varnish by sliding a bolt through the hole or using a drill (not included).
1.
2.
1
1
9, 8 & 10
3
1
8, 9 &10
3
FIGURE 1
1
1
9, 8 & 10
3
1
8, 9 &10
3
FIGURE 1
07f
7
