Page 4SKU 90729 For technical questions, please call 1-800-444-3353.
Assembly
Ground Staked Installation
See the Assembly Drawing on page 7.
Note: Ground Stake parts assemble by simply slip-fitting them together.
1. Assemble the Ground Stake by fitting a Stake Connector (3) into the Pointed Ground
Stake (4), then add, a Ground Stake Tube (2) to the Stake Connector (3). Then, add
another Stake Connector (3) and another Ground Stake Tube (2). Lastly, insert the top
Ground Stake Tube (2) into the Light Fixture (1).
2. Choose a location away from other night time light sources and dig a hole
approximately 6 inches in the ground. If the ground is hard, soak it with water prior to
digging.
3. Work the Light stake into the ground without forcing it or hammering it. Forcing or
hammering will break the Light Stake and permanently damage the Solar Light. Fill in
the dirt around the Stake and make sure it is stable. See FIGURE 1.
Wall Bracket Installation
1. At the desired location, use the holes in the Wall Bracket (5) for a template and draw
two screw hole circles on the mounting surface. Predrill, being careful not to drill into
hidden electrical wires or cables. Make sure the wall is solid or has a stud behind the
surface that will hold the weight of the Solar Light. Mount the Wall Bracket (5) with the
two screws provided.
2. Insert the Light Fixture (1) into the Wall Bracket (5) making sure the light sensor is
pointing away from any other night time light source. See FIGURE 2.
FIGURE 1
FIGURE 2
Assembled
Ground Stake
Light Fixture (1)
Light Fixture (1)
Wall Bracket (5)
