Specifications
ITEM DESCRIPTION
Power Requirement 110 VAC, 60 Hz, single phase, 13.8 startup amps
Motor 2800 RPM, double insulated; centrifugal switch brake
Line Cord
30 inch, 16 AWG, UL approved; (requires connection to
an outdoor rated, 10 amp extension cord, not supplied)
Power Switch Hand squeeze with lock-off safety button
Cutting Blade
12 inch hardened steel;
adjustment: 1 (min) - 3 (max) inches
Height Adjustment Three position front and rear axles, spring loaded
Wheel Size 4-3/4 inch diameter
Overall Dimensions 15 (W) x 40 (L) x 37 (H) inches; with 16 inch (W) handle
Weight 25.9 lbs.
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using this product, basic safety precautions should always be followed
to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this product and tools!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children should not be allowed to use the Lawnmower. Children
must never be allowed in the cutting area. Do not let them handle machines, tools, or
extension cords.
4. Store idle equipment. When not in use, this product must be stored in a dry location
to inhibit rust. Always lock up tools and keep out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small tool or attachment to
do the work of a larger industrial tool. There are certain applications for which this
product was designed. It will do the job better and more safely at the rate for which
it was intended. Do not modify this product and do not use for a purpose for which it
was not intended.
6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid footwear
REV 02i
