Page 2For technical questions, please call 1-800-444-3353.SKU 03551 03552
SPECIFICATIONS
Save this manual
You will need the manual for the safety
warnings and cautions, assembly instructions,
operating procedures, maintenance
procedures, trouble shooting, parts list,
and diagram. Keep your invoice with this
manual. Write the invoice number on the
inside of the front cover. Keep both this
manual and your invoice in a safe, dry place
for future reference.
SAFETY WARNING &
CAUTIONS
WARNING: When using electric tools,
machines, or equipment, basic safety
precautions should always be followed
to reduce the risk of re, electric
shock, and personal injury. READ ALL
INSTRUCTIONS BEFORE USING THIS
TOOL!
KEEP WORK AREA CLEAN.1. Cluttered
areas invite injuries.
OBSERVE WORK AREA CONDITIONS.2.
Do not use machines or power tools in
damp, wet, or poorly lit locations. Don’t
expose to rain. Keep work area well lit.
Do not use electrically powered tools
in the presence of ammable gases or
liquids.
KEEP CHILDREN AWAY.3. Children must
never be allowed in the work area. Do
not let them handle machines, tools, or
extension cords.
STORE IDLE EQUIPMENT.4. When not
in use, tools must be locked up in a dry
location to inhibit rust. Always lock up
tools and keep out of reach of children.
DO NOT FORCE THE TOOL.5. It will do
the job better and more safely at the rate
for which it was intended. Do not use
inappropriate attachments in an attempt
to exceed the tool’s capacities.
USE THE RIGHT TOOL FOR THE JOB. 6.
Do not attempt to force a small tool or
attachment to do the work of a larger
industrial tool. Do not use a tool for a
purpose for which it was not intended.
DRESS PROPERLY.7. Do not wear loose
clothing or jewelry as they can be caught
in moving parts. Protective, electrically
non-conductive clothes and non-skid
footwear are recommended when
working. Wear restrictive hair covering to
contain long hair.
USE EYE AND EAR PROTECTION.8.
Always wear ANSI approved chemical
splash goggles when working with
chemicals. Always wear ANSI approved
impact safety goggles at other times.
Wear a full face shield if you are
producing metal lings or wood chips.
Wear an ANSI approved dust mask or
respirator when working around metal,
wood, and chemical dusts and mists.
DO NOT ABUSE THE POWER CORD.9.
Do not yank it to disconnect it from the
receptacle. Do not carry tools by the
cord.
DO NOT OVERREACH.10. Keep proper
footing and balance at all times. Do not
reach over or across running machines.
3551 3552
Capacity 1/2 Ton 1 Ton
Maximum Height 4-1/2” 5-1/2”
Maximum Diameter 6-1/2” 8”
Largest Arbor 1” 1-1/8”
Ram Square 3/4” 1”
Height of Press 10” 13”
Base Dimensions 4” x 9-1/2” 5” x 11”
Leverage Ratio 20:1 20: 1
