GEH-5304A
32
Table 14
Recommended Spare Parts
Number of Duplicate Motors in Service
More
Description 1 2-4 5-10 10-20 Than 20
With or Without Electrical Shop Facilities
Complete Machine --- --- --- 1 2
Ball Bearing (Sets) 11123
Brushes (Sets) 246810
Brushholders (Sets) --- 1/2 1/2 1 1
Brushholder Springs (Sets) 1/2 1122
Armature (Complete) * ---1122
Wound Frame ** --- --- 1 2 2
Blower Ventilated Motors:
Blower Motors ---1122
With Electrical Shop Facilities:
Shaft --- --- --- 1 1
Armature Rewinding Supplies ---1123
* If shop facilities are available, the quantity of armatures may be reduced by stocking the armature parts listed in the
second group.
** Factory wound frames are wound using specialized equipment and then varnish dipped. Although it is physically
possible for a motor shop to rewind a failed field winding, experience has shown that rewinds cannot offer an accept-
able service life due to the difficulty in winding the many turns of small diameter wire without damage.
