SPECIFICATIONS
Specifications are correct at time of printing and are
subject to change without notice.
ENGINE:
Briggs & Stratton*
Make Briggs & Stratton
Model 543577-0110-E1
Displacement 54.62 Cu. in (895 cc)
Electrical System 12 Volt, 20 amp. Alternator,
Battery: 340 CCA
Oil Capacity 2.4 US qt. (2.25 L) w/ Filter
Power Ratings: The gross power rating for individual gas engine
models is labeled in accordance with SAE (Society of Automotive
Engineers) code J1940 (Small Engine Power & Torque Rating
Procedure), and rating performance has been obtained and
corrected in accordance with SAE J1995 (Revision 2002-05).
Torque values are derived at 3060 RPM; horsepower values are
derived at 3600 RPM. The gross power curves can be viewed at
www.BRIGGSandSTRATTON.COM. Net power values are taken
with exhaust and air cleaner installed whereas gross power values
are collected without these attachments. Actual gross engine power
will be higher than net engine power and is affected by, among
other things, ambient operating conditions and engine-to-engine
variability. Given the wide array of products on which engines are
placed, the gas engine may not develop the rated gross power
when used in a given piece of power equipment. This difference is
due to a variety of factors including, but not limited to, the variety
of engine components (air cleaner, exhaust, charging, cooling,
carburetor, fuel pump, etc.), application limitations, ambient
operating conditions (temperature, humidity, altitude), and engine-
to-engine variability. Due to manufacturing and capacity limitations,
Briggs & Stratton may substitute an engine of higher rated power
for this Series engine.
CHASSIS:
Fuel Tanks Capacity: 56 lbs net
Rear Wheels Tire Size: 24 x 12.00 -12
Inflation Pressure: 15 psi (1,03 bar)
Front Wheels Tire Size: 13 x 6.50 - 6
Inflation Pressure: 25 psi (1,72 bar)
TRANSMISSIONS:
(Pumps)
Hydro-Gear PJ-12:
12cc Pumps fit models: S/N: 2014192366 - 2014192366
Hydro-Gear PR-16:
16cc Pumps fit models: 37HP DFI Models: 2015308756 & Below;
All other models: S/N: 2014192367 - 2015308756)
Hydro-Gear PR-2HCC-GV1X-XXXX:
S/N: 2015308757 & Above
(Wheel Motors)
Parker TF-024:
(S/N: 2015122497 & Below)
Parker TG-024:
(S/N: 2015122498 & Above)
Type Pump and Wheel Motor
Hydraulic Fluid Mobil 1™ 15W-50 synthetic oil or
Castrol Syntec™ 5W-50 oil
Speeds Forward: 0-10 MPH (0-16.09 km/h)
@ 3400 rpm Reverse: 0-5 MPH (0-8.05 km/h)
DIMENSIONS:
Overall Length 82” (208,3 cm)
Overall Width
61” Side Discharge 73” (183,4 cm)
72” Side Discharge 85” (216 cm)
Height 71” (180,3 cm) with Roll Bar Up
55” (139,7 cm) with Roll Bar Down
Weight (apx.) 2150 lbs. (975 kg)
