Supplemental Parts List - Tank Mount Group
REF NO. PART NO. QTY DESCRIPTION
1 5407570B 1 MOUNT, TANK MOUNT, PROPANE, RH - RED
2 5407592B 1 MOUNT, TANK MOUNT, PROPANE, LH - RED
3 5404213B 1 PLATE, BRACKET, REGULATOR MOUNT, PROPANE - RED
4 5403947B 2 PLATE, BRACKET, TANK MOUNT - RED
5 5403521B 1 WELD, TANK MOUNT - LH (S/N: 2014953566 & Below)
6 5403520B 1 WELD, TANK MOUNT - RH (S/N: 2014953566 & Below)
7 5023173 2 CLAMP, HOSE, 1” DIAMETER
8 5025013X8 8 BOLT, 3/8-16 X 1 GD5 YZ
9 5025156 8 WASHER, 3/8 SAE
10 5025394 8 NUT, 3/8-16 HEX NYLOCK FLANGE
11 5403618B 1 PLATE, SWITCH, GUARD, LH - RED
12 5403617 1 PLATE, SWITCH, GUARD, RH - RED
13 5025010X16 2 BOLT, 1/4-20 X 2”, GD5 (For bolting hose clamps to engine.)
14 5025154 6 WASHER, 1/4 SAE (Qty: 2 for bolting hose clamps to engine.)
15 5025010X8 4 BOLT, 1/4-20 X 1” GD5
16 5025011X6 8
BOLT, 5/16-18 X 3/4 GD5 (Not shown. For bolting propane tank
strap brackets tank mount weldments.)
17 5025156 6 NUT, 1/4-20 HEX SERRATED FLANGE
18 5025155 28 WASHER, 5/16 SAE
19 5025392 28 NUT, 5/16-18 HEX NYLOCK FLANGE
20 5025011X8 18 BOLT, 5/16-18 X 1 GD5 YZ
21 5025011X12 2 BOLT, 5/16-18 X 1-1/2” GD5 YZ
22 5101427 2 STRAP, BRACKET KIT, PROPANE TANK (Not shown.)
23 5101707 2 TANK, PROPANE - WORTHINGTON
24 - 1 ENGINE, BRIGGS & STRATTON, PROPANE READY
25 5101425 1 SWITCH, OIL PRESSURE (Not illustrated.)
26 5102666 2 DECAL, WARNING, VAPOR VALVE
27 5406713B 1 WELD, TANK MOUNT - LH (S/N: 2014953567 & Above)
28 5406714B 1 WELD, TANK MOUNT - RH (S/N: 2014953567 & Above)
