- 12 -
2.9 TIRES
36” Drive 48” & 52” Drive Front Caster
Pneumatic (Air-Filled) Pneumatic (Air-Filled) Semi-Pneumatic
Size 16 x 6.50-8 16 x 7.50-8 9 x 3.50-4
Quantity 2 2 2
Tread Turf Master Turf Master Smooth
Ply Rating 4 4
Pressure 14 psi (97 kPa) 14 psi (97 kPa)
2.10 DECK
2.10.1 Cutting Width:
Model 36 in. ........................................35.25 in. (89.5 cm)
Model 48 in. ........................................47.25 in. (120.0 cm)
Model 52 in. ........................................52.00 in. (132.1 cm)
2.10.2 Discharge: Right Side
2.10.3 Blade Size:
Model 36 in. ..............18.00 in. (45.7 cm) ..............Qty. 2
Model 48 in. ..............16.25 in. (41.3 cm) ..............Qty. 3
Model 52 in. ..............18.00 in. (45.7 cm) ..............Qty. 3
2.10.4 Type of Drive: Manual engagement of belt with over-center lock. Belt tension is
adjustable via turnbuckle.
2.10.5 Deck Mounting: Full floating deck is attached to out-front support frame,
removable for service.
2.10.6 Cutting Height: Adjusts in 1/2” (.63 cm) increments from 1.5” (3.8 cm) to 4 1/2”
(11.4 cm).
2.11 DIMENSIONS
2.11.1 Overall Width: 36” 48” 52”
46.25” 58.25” 62.6”
Discharge chute down
(117.5 cm) (148.0 cm) (159.0 cm)
Discharge chute up
36.1” 48.1” 53.0”
(Transport only)
(91.7 cm) (122.2 cm) (134.62 cm)
2.11.2 Overall Length: 36” 48” 52”
77.7” 73.7” 75.9”
Standard Pistol Grip
Handles
(197 cm) (187 cm) (193 cm)
77.0” 73.0” 75.2”
ECS Handles
(196 cm) (185 cm) (191 cm)
2.11.3 Curb Weight: 36” 48” 52”
537 lbs. 589 lbs. 617 lbs.
Standard Pistol Grip
Handles
(244 kg) (267 kg) (280 kg)
547 lbs. 599 lbs. 627 lbs.
ECS Handles
(248 kg) (272 kg) (284 kg)
∗ Weights will vary slightly depending on engine and electric start options.
2.11.4 Overall Height:
Standard Pistol Grip Handles ...... 42” (107 cm) (all models)
ECS Handles............................... 44.1” (112 cm) (all models)
2.11.5 Tread Width (to outside of tires):
36” Model .........................35.0” (88.9 cm)
48” Model .........................39.4” (100.1 cm)
52” Model .........................39.4” (100.1 cm)
