Maintenance
Note: Do Not use anti-seize on wheel hub.
• Style B (yellow zinc):
1. Remove and discard the cotter pin.
2. Torque the slotted nut to 200 ft-lb (271 N-m).
3. Check distance from bottom of slot in nut to
inside edge of hole. Two threads (0.1 inch) or
less should be showing.
Figure 27
1. 0.1 inch max 2. No more than two
threads (0.1 inch max)
should be showing here.
4. If more than two threads (0.1 inch) are
showing remove nut and install washer (P/N
1-523157) between hub and nut.
5. Torque the slotted nut to 200 ft-lb (271 N-m).
6. Then tighten nut until the next set of slots line
up with the cross hole in shaft. Do Not loosen
nut to align the slot. If required, tighten to
the next set of slots.
7. Install new cotter pin (P/N 1-806800).
Note: Do Not use anti-seize on wheel hub.
Check Engine Coolant Level
(Kawasaki Liquid-Cooled
Only)
Service Interval: Before each use or daily
1. Stop engine and wait for all moving parts to stop.
Make sure unit is on a level surface.
2. Check with engine cold.
3. View coolant level in overow bottle located at
the right rear of the engine below the radiator.
Coolant level should be at the indicator line on
the overow bottle.
WARNING
Engine coolant is hot and pressurized and
radiator and surrounding parts are hot. Spray
or steam from hot, pressurized liquid in the
engine cooling system and touching a hot
radiator may cause severe burns.
Allow the engine to cool completely before
removing the radiator cap or servicing any
component of the cooling system.
CAUTION
Engine coolant is toxic. Swallowing coolant
can cause poisoning.
• Do not swallow.
• Keep out of reach of children and pets.
4. If the coolant level is low, remove the radiator
cap and ll to the bottom of the ller neck.
Units should only be lled with a 50/50 mix
of Dex-Cool© extended life coolant and water.
Dex-Cool© can be identied by its orange color.
Change Engine Coolant
(Kawasaki Liquid-Cooled
Only)
Service Interval: Every 4,000 hours/Every 4
years (whichever comes
rst) Dex-Cool©©
©
extended
life coolant (orange color)
1. Stop engine, wait for all moving parts to stop, and
remove key. Engage parking brake. Machine must
be positioned on level surface.
2. Place a drain pan under the drain plug.
3. Drain coolant when engine is cool. Coolant may
be drained from the radiator by turning the drain
plug counterclockwise.
38
