Engine Deck Assembly (continued)
Ref.
Part Number
Qty. Description
1 103-3499 1
Rear Deck (117-3521-01)
W/Decals
2 1-323500 1 Transmission
3 1-324340 2
Asm, Coupling, W/Guard
And Zerk
4 1-323502 2
Shaft-Transmission
5
103-2587 1 Adapter
6 1-323252 2
Bearing-Shaft
●
7
1-323254 2
Flange-Output
8 103-6511 2
Sheave-Transmission
●
9 32151-62 2 Ring-Retaining
10 1-805005 4
Washer-Lock 5/16 Heavy
11 1-373034 1 Washer
12 3245-41 2
Setscrew-1/4-20 X 3/8
■
13 1-323280 1 Belt, Transmission
14 3290-357 3
Nut-Whizlock 3/8-16
15 3296-39 1
Nut-Nyloc 3/8-16
16 103-3498 1
Shifter Plate (1-323387-03)
W/Decals
17 1-323389-03 2
Bracket-Plate, Shift
18 3230-1 2
Bolt-Carriage 5/16-18 X 3/4
19 32128-20 2
Nut-Whizlock 5/16-18
20 51-4220 2
Guard-Coupler
21 103-1666 1
Sheave-Transmission
●
22 103-1668 1
Sheave
●
23 103-4177 1 Key
24 302-19 2
Zerk-1/4-28 Str
25 103-1733 1
Grip
26 323-7 4
Screw-HH 3/8-16 X 1 1/4
Ref.
Part Number
Qty. Description
27 323-13 1
Screw-HH 3/8-16 X 2 3/4
28 1-803310 2
Setscrew-5/16-18 X 3/8
■
29 1-633453 1
Spacer-Clutch
30 1-603610 2
Washer-Spring Disc 7/16
31 9264964 4
Bolt-HWH 5/16-18 X 3/4 Tap
32 1-303186 1 Bellcrank
33 1-323278 1
Sheave-Transmission
●
34 1-323379 1 Washer
35 98-5975
5
Washer-Spring Disc 3/8
36 3296-6 1
Nut-Nyloc 3/8-24
37 3257-5 3
Key-Woodruff #9 3/4 X 3/16
38 1-303282 1
Switch-Start, Neutral
39 3231-6 1
Bolt-Carriage 3/8-16 X 2
40 3256-5 2
Washer-7/16 Std
41 1-323285 1 Pulley-Idler, Flat
42 3256-24 1
Washer-3/8 Sae
43 321-3 4
Screw-HH 1/4-20 X 5/8
44 3296-42 4
Nut-Nyloc 1/4-20
45 1-603403 1
Bolt-Shoulder
46 116-3702 1
Screw, HH 7/16-20 X 1 1/4
■
47 1-513051 1
Switch-N.O.
48 322-3 4
Screw-HH 5/16-18 X 3/4
49 3290-500 2
Screw-PPH #10-24 X 5/8
50 1-633181 1 Plate-Tapped
51 103-1606 1
Asm Shift Lever, W/Grip
53 114-3550 4
Washer-Lock, Spring
54 114-3549 4 Nut-M8
55
1-653313 2
Gasket-Exhaust
56 116-4396 1
Mufer
●
Apply anti-seize compound in bore.
■
Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on threads.
9 4500-764A
