ECS Upper Handle and Controls (continued)
Ref.
Part Number
Qty. Description
1 116-4079 1
Wld, Lever, Opc (LH)
▲
2 1-303365 2 Bushing-Nylon
3 1-803322 2
Setscrew-5/16-24 X 5/16
■
4 103-0769-03 1
Wld, Opc Axle Lever
5
1-303363 1
Spring-Extension
6 1-303335 1
Tie-Cable 7 15/16 (Large)
7
1-807513 2
Bolt-Carriage #10-24 X 1/2
8 3296-2 2
Nut-Nyloc #10-24
9 116-2426 1
Cable, Throttle
10 116-4080 1
Wld, Opc Lever (RH)
▲
11 1-303020 1
Grip-Lever
12 103-1629 1
Lever, Clutch W/Grip
13 3296-29 2
Nut-Nyloc 5/16-18
14 3256-4 1
Washer-3/8 Std
15 103-0027 2 Bushing-Lever, Drive
16 1-806003 2
Hairpin-Cotter
17 103-1627 1 Linkage, Upper
18 103-1604 2 Linkage, Wheel Drive
19 1-543296 1
Grommet
20 103-0815 2
Grip-Bar, Handle
21 1-303435 6
Washer-Spring Disc 1/4
22 103-1631 1
Latch, Thumb (LH) (Not
Shown)
●
22 103-1630 1
Latch, Thumb (RH)
23 3296-42 1
Nut-Nyloc 1/4-20
24 103-0770-03 1 Wld, Handle
25 1-303088 1
Clip-Cable
26 323-6 4
Screw-HH 3/8-16 X 1
35 103-0498 1 Nut-Ignition
39 33094-00 1 Washer
41 116-2661 1 Harness-Wire
42 3256-22 1
Washer-1/4 Sae
43 321-4 1
Screw-HH 1/4-20 X 3/4
44 1-403121 1
Switch-Key
Ref.
Part Number
Qty. Description
44:1 1-603511 1 Key-Ignition
44:2 103-2106 1 Key-Exmark Logo
45 1-633181 1 Plate-Tapped
46 3296-39
5
Nut-Nyloc 3/8-16
47 3290-500 2
Screw-PPH #10-24 X 5/8
48 1-513051 1
Switch-N.O.
49 1-323229 1
Clip-Loom 3/8
50 1-303287 6
Tie-Cable 5 1/2 (Small)
51 1-323430 1 Module-Interlock
52 323-14 1
Screw-HH 3/8-16 X 3
53 322-9 2
Screw-HH 5/16-18 X 1 3/4
54 1-413152 4
Bushing-Sleeve
55
116-4081 1 Lever, Drive LH
56 3219-3 2
Nut-Hex 3/8-24
57
321-14 2
Screw-HH 1/4-20 X 2 3/4
58 32128-33 12
Nut-Whizlock 1/4-20
59 103-0464 2
Pin-Spring 1/8 X 1/2
60 3256-22 10
Washer-1/4 Sae
61 103-0235 2
Screw-HH 1/4-20 X 1 1/8
W/Nylon
■
62 116-4082 1 Lever, Drive RH
63 3220-3 4
Nut-Jam 3/8-24
64 109-4934 1
Asm, Console
(109-4649-03) W/Decals
65 321-3 10
Screw-HH 1/4-20 X 5/8
66 103-2513 1 Asm, Drive Lever RH
67 103-2514 1 Asm, Drive Lever LH
68 103-2463 2 Balljoint
69 103-0489-03 1
Bracket, Opc Axle
70 103-1796 1
Cable-Choke
71 103-1797-01 1
Bracket-Cable, Choke
72 1-633080 1
Spacer
73 3256-14 1
Washer-#10 Std
75
33114-016 1
Screw-HH M8-1.25 X 16Mm
●
Not illustrated
■
Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on threads.
▲
Use Pro-Lock retaining type, Part no. 1-840023 (.5cc tube) on inside of bore of OPC hub.
13 4500-764A
