- 28 -
FRONT WHEEL ASSEMBLY REAR WHEEL ASSEMBLY
FIGURE 30 FIGURE 31
Assembling the Wheels
1. Re-install wheel assembly as shown in Figures 30 or 31.
2. Connect the wire to the spark plug.
6. STORAGE
6.1 Preparing the fuel system.
To prepare the lawn mower for off season storage, perform the recommended
maintenance procedures.
Store the lawn mower in a cool, clean, dry place. Cover the lawn mower to keep it clean
and protected.
WARNING
POTENTIAL HAZARD
♦ Gasoline can vaporize if you store it over long periods
of time.
WHAT CAN HAPPEN
♦ Gasoline vapors can explode if they come into contact
with an open flame.
HOW TO AVOID THE HAZARD
♦ Do not store gasoline over long periods of time.
♦ Do not store the lawn mower with gasoline in the fuel
tank or the carburetor in tan enclosure with an open
flame. (For example, a furnace or a water heater pilot
light.)
♦ Allow the engine to cool before storing it in any
enclosure.
Empty the fuel tank when mowing the last time before storing the lawn mower.
1. Run the lawn mower until the engine stops from running out of fuel.
2. Prime the engine and start it again.
3. Allow the engine to run until it stops. When you can no longer start the engine it is
sufficiently dry.
6.2 Preparing the Engine
1. While the engine is still warm, change the oil from the crankcase. Refer to Section
5.13 Changing the Engine Oil.
2. Remove the spark plug (Fig. 8).
