- 7 -
2. SPECIFICATIONS
2.1 MODEL NUMBER: M266KASPC
2.2 ENGINE
2.2.1 Engine Specifications: See your engine owner's manual.
2.2.2 RPM (No Load): 3600 rpm
2.3 FUEL SYSTEM
2.3.1 Capacity: 4 qt. (3.8 liter)
2.3.2 Type of Fuel: Use only clean, fresh, regular grade, unleaded gasoline with the
pump sticker octane rating of 87 or higher. In countries using the research
method, it should be 90 octane minimum.
2.3.3 Fuel Filter: Non–replaceable, on left side of tank
2.3.4 Fuel Shut Off Valve: on left side of tank
2.4 TRANSMISSION
2.4.1 3 speeds forward
Speed range: 1
st
- 2.0 mph (3.2 km/h)
2
nd
- 2.9 mph (4.6 km/h)
3
rd
- 4.1 mph (6.6 km/h)
2.5 DECK
2.5.1 Cutting Width: 26.1” (66 cm)
2.5.2 Blade Brake: When the blade engagement control is moved to the disengaged
position a friction brake pad stops the rotation of the blades.
2.5.3 Cutting Height: Adjusts in 1/2" (.64 cm) increments from 1” to 4” (2.5 cm-10.6 cm).
2.6 DIMENSIONS
2.6.1 Overall Width: 27” (69 cm)
2.6.2 Overall Length and Height (Adjustable):
Handle Setting Length Height
High 69” (175.2 cm) 44” (111.8 cm)
Low 73” (185.4 cm) 37.5” (95.3 cm)
2.6.3 Curb Weight: 160 lbs (73 kg)
PART NO.: 1-213240
LOCATION: On Rear Discharge
Chute Cover
PART NO.: 103-6329
LOCATION: Top Surface of
Shifter Control
PART NO.: 103-6328
LOCATION: Top Surface of
Throttle Control
