Maintenance
Maintenance Service
Interval
Maintenance Procedure
Every 4,000 hours
•
Change engine coolant. Dex-Cool© extended life coolant (orange color)
Monthly
• Check the battery charge.
Yearly
• Grease the fold lock pin.
• Grease the rear caster pivot.
• Grease the belt idlers.
• Grease the motion control pivots.
• Grease the transfer spring ends.
• Lubricate the caster wheel hub(s).
• Lubricate the motion control shaft.
• Change the hydraulic lter.
Periodic Maintenance
Check Engine Oil Level
Service Interval: Before each use or daily
1. Stop engine and wait for all moving parts to stop.
Make sure unit is on a level surface.
2. Tilt seat forward and raise hood to gain access
to access to engine area.
3. Check with engine cold.
4. Clean area around dipstick. Remove dipstick and
wipe oil off. Reinsert the dipstick and push it all
the way down into the tube. Remove the dipstick
and read the oil level.
5. If the oil level is low, wipe off the area around the
oil ll cap, remove cap and ll to the “FULL”
mark on the dipstick. Use oil as specied in
Engine Owner’s Manual. Do Not overll.
Important: Do Not operate the engine with the
oil level below the “LOW” (or “ADD”) mark on
the dipstick, or over the “FULL” mark.
Check Engine Coolant Level
Service Interval: Before each use or daily
1. Stop engine and wait for all moving parts to stop.
Make sure machine is on a level surface.
2. Tilt seat up and tilt hood forward to gain access
to the cooling area.
3. Check with engine cold.
4. View coolant level in overow bottle on the left
side of the engine. Coolant level should be at the
indicator line on the overow bottle.
5. If the coolant level is low, remove the cap to the
overow bottle and ll to the indicator line. Use
coolant specied in Specications section.
Note: Units should only be lled with
Dex-Cool© extended life coolant, which can be
identied by its orange color.
WARNING
Engine coolant is hot and pressurized and
radiator and surrounding parts are hot. Spray
or steam from hot, pressurized liquid in the
engine cooling system and touching a hot
radiator may cause severe burns.
Allow the engine to cool completely before
removing the radiator cap or servicing any
component of the cooling system.
CAUTION
Engine coolant is toxic. Swallowing coolant
can cause poisoning.
• Do Not swallow.
• Keep out of reach of children and pets.
24
