Operation
The buzzer is a warning signal that the engine
is overheating or the oil pressure is low. See the
Troubleshooting section.
Pre-Start
Fill fuel tank. For best results use only clean, fresh
diesel fuel, with a cetane rating of 40 higher
Note: Do Not use kerosene or gasoline instead
of diesel fuel. Failure to observe this caution will
damage the engine.
Do Not add oil to fuel.
Do Not overll fuel tank. Never ll the fuel tank so
that the fuel level rises above a level that is 1/2 inch
(13 mm) below the bottom of the ller neck to allow
for fuel expansion and prevent fuel spillage.
Make sure you understand the controls, their
locations, their functions, and their safety
requirements.
Refer to the Maintenance section and perform all the
necessary inspection and maintenance steps.
Operating Instructions
Raise the Rollover Protection System
(ROPS)
Important: Lower the roll bar only when
absolutely necessary.
1. Remove the hairpin cotter pins and remove the
two roll bar pins (Figure 5).
2. Raise the roll bar to the upright position and
install the two pins and secure them with the
hairpin cotter pins (Figure 5).
Important: Always use the seat belt with the
roll bar in the raised position. Ensure that the
rear part of the seat is secured with the seat
latch.
Figure 5
1. Roll bar 3. Pin
2. Raised position 4. Hairpin cotter pin
Starting the Engine
1. Move the motion control levers out to the neutral
lock position.
2. Pull up and back on the parking brake lever to
engage the parking brake.
3. Push in on the PTO switch to the “STOP”
position.
Note: It is not necessary for the operator to be
in the seat to start the engine.
4. On a warm engine, place the throttle in the
“SLOW” position.
5. On a cold engine, (below 14°F (-10°C)), place the
throttle in the “MIDWAY” position.
Note: Do Not use fuel left over from summer.
6. Turn ignition switch to the “ON” position.
Depress the glow plug switch and the glow plug
light will turn on. Hold switch as required by
chart below. Turn the ignition switch to the
“START” position. Release the ignition switch as
soon as the engine starts.
19
