Operation
Driving the Machine
CAUTION
Machine can spin very rapidly by positioning
one lever too much ahead of the other.
Operator may lose control of the machine,
which may cause damage to the machine
or injury.
• Use caution when making turns.
• Slow the machine down before making
sharp turns.
Important: To begin movement (forward or
backward) the operator must be in the seat, the
brake lever must be disengaged (pushed down)
before the motion control levers can be moved in
or the engine will stop.
When levers are centered in the T-slot the drive
system is in the neutral position. With levers moved
out in the T-slot the drive system is in the neutral lock
position (Figure 6).
Figure 6
1. Handles Out (Neutral
Lock)
5. Neutral
2. Handles In (Neutral)
6. Reverse
3. Front of Unit
7. Neutral Lock
4. Forward
Driving Forward
1. Release the parking brake.
2. Move the motion control levers inward to the
center to the neutral unlocked position.
3. To move forward in a straight line apply equal
forward pressure to both levers.
To turn left or right, pull the motion control lever
back toward neutral in the direction desired.
The machine will move faster the farther the
motion control levers are moved away from
neutral.
4. To stop, pull the motion control levers back to
the neutral position.
Figure 7
1. Handles Out (Neutral
Lock)
4. Forward
2. Handles In (Neutral)
5. Reverse
3. Front of Unit
Driving in Reverse
1. Move the motion control levers inward to the
center to the neutral unlocked position.
2. To move rearward in a straight line applying equal
pressure pull both motion control levers rearward.
To turn left or right, release pressure on the
motion control lever toward the direction desired.
3. To stop, push the motion control levers to the
neutral position.
21
