52” DECK GROUP (cont.)
-8-
Item Part No. Description Qty.
1 109-6388 Kit, Anti-Scalp Roller ..............................3
1:1 112-3977 Bolt, Shoulder ........................................1
1:2 1-603299 Roller, Anti-Scalp ...................................1
1:3 104-8301 Nut, Nyloc 3/8-16 Flg .............................1
2 109-8744 Asm, Cutter Housing Complete..............3
3 103-6402 Blade, Notched 18.0 ..............................3
Q
109-6390 Blade. Mulch..........................................3
109-6392 Blade, High Lift ...................................... 3
4 109-3671 Sheave, Blade Drive ..............................3
5 109-3410 Hanger, Deck.........................................4
6 109-8788 Bushing, Flanged...................................8
Item Part No. Description Qty.
7 3231-25 Bolt, Carriage 3/8-16 x 1 1/4.................. 8
8 104-8301 Nut, Nyloc 3/8-16 Flg ............................. 8
9 109-3661 Belt........................................................ 1
10 109-6393 Kit, Washout Port................................... 1
10:1 95-2747 Fitting, Washout Port ............................. 1
10:2 46-6290 O-Ring................................................... 1
10:3 93-6083 Screw, HWH 1/2-20 x 1/2 Taptite........... 2
10:4 95-3270 Connector, Hose.................................... 1
13 109-8854 Pin, Chute.............................................. 1
14 109-6886 Spring.................................................... 1
15 109-5151 Chute, Deflector..................................... 1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & sheaves. DO NOT
use a copper or nickel based anti-seize.
Q Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N 109-5982.
