GEARBOX COMPONENTS FOR 103-3460 & 103-3387
8
Item
Part No.
Description
Qty.
1 109-0188 Asm, Input Pinion 42”.............................1
109-0189 Asm, Input Pinion 48”.............................1
2V 109-0190 Center Housing W/Plugs........................1
3V 109-0191 End Housing W/Plugs & Race ...............2
4O 109-0192 Output Shaft, Gear & Brgs (42” LH) ......1
O
109-0193 Output Shaft, Gear & Brgs (48” LH)......1
5O 109-0194 Output Shaft, Gear & Brgs (42” RH)......1
O
109-0195 Output Shaft, Gear & Brgs (48” RH)......1
6R 109-0196 Output Cap W/Race...............................2
7VR 109-0197 Asm, Connector Tube 42” Short.............1
Item
Part No.
Description
Qty.
V
109-0198 Asm, Connector Tube 48” Short............1
8VR 109-0199 Asm, Connector Tube 42” Long.............1
V
109-0200 Asm, Connector Tube 48” Long.............1
9 109-0201 Kit, Output Seal .....................................2
10 109-0202 Seal, Input.............................................1
11 109-0203 O-ring ....................................................7
12 109-0204 Washer, Cupped....................................1
13 109-0205 V-ring.....................................................1
14 93-3987 Screw, HH 3/8-24 x 1 1/4 Gr8................28
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Fill gearbox sections to drain/fill plug with Mobil SHC (synthetic) 75w-90 gear lube oil
V Includes o-rings, item #11
O Includes (1) output seal assembly, item #9
Apply bead of Mobil HTS grease (P/N 103-5217 1.5 oz packet) between seal, item #10 and v-ring, item #13.
S Does not include screw, item #14.
