DECK GROUP
4
Item
Part No.
Description
Qty.
1 1-403005 Danger, Decal........................................2
2 1-413425 Spacer, Deck Support............................4
3 1-513690 Clip, Deck Holdup Rod...........................1
4 109-2365 Bumper..................................................2
5 1-613204 Balljoint..................................................2
6 1-803075 Screw, Truss Head #10-24 x 3/4............8
7 1-806003 Hairpin, Cotter........................................2
8 30-8770 Washer..................................................2
9 67-7490 Key, Machine 1/4 x 1/4 x 1 1/2...............1
10 68-8340 Decal, Blade Bolt Torque.......................2
11 92-5816 Bolt, Blade 1/2-20 x 2 1/4.......................2
12 98-5954 Decal, Danger........................................2
13 99-0283 Bolt, Shear 1/4-20 x 7/8 .........................4
14 1-808280 Pin, Clevis 5/16 x 1................................2
15 103-9487 Asm, Discharge Tube ............................1
16 109-0321 Asm, Front Deck Height Adj...................2
17 109-2228-03 Guard, Plenum.......................................1
18 103-3700 Roller, Deck...........................................2
19 109-0322 Asm, Rear Deck Height Adj. (42”)..........2
109-0323 Asm, Rear Deck Height Adj. (48”)..........2
20 103-9485 Asm, Drive Shaft W/Decal .....................1
103-9327 Asm, Cross "U" Joint .............................2
103-9328 Yoke, Keyed ..........................................1
103-9329 Yoke, Quick Disconnect.........................1
21 103-4230 Spacer, Roller........................................2
22 103-4974 Hinge.....................................................1
23 103-5868-01 Wld, Spring Mount.................................1
24 103-5979 Guard, PTO ...........................................1
25 103-6183-03 Bracket, PTO Guard ..............................1
26 103-6230 Decal, Cutting Height Adjustment ..........2
27 103-6290-03 Plate, Drive Line Cover ..........................1
28 103-7353 Hairpin, Cut Height.................................4
29 103-7705 Driver, Blade..........................................2
30 103-7994 Balljoint..................................................1
31 103-8307 Latch, Deck............................................1
32Q 103-8363 Asm, Deck Latch....................................1
33 103-8425 Decal, Driveline......................................1
34 103-8496 Nut, Jam 7/8-9.......................................2
35 103-8610 Stand-Off, 1/2 Hex.................................2
36 103-8841 Spring....................................................1
37 321-2 Screw, HH 1/4-20 x 1/2..........................2
38 322-3 Screw, HH 5/16-18 x 3/4........................3
39 322-5 Screw, HH 5/16-18 x 1...........................5
Item
Part No.
Description
Qty.
40 323-11 Screw, HH 3/8-16 x 2 1/4 (42”) ..............2
323-8 Screw, HH 3/8-16 x 1 1/2 (48”) ..............2
41 323-7 Screw, HH 3/8-16 x 1 1/4.......................4
42 323-9 Screw, HH 3/8-16 x 1 3/4.......................1
43 325-14 Screw, HH 1/2-13 x 3 1/2.......................2
44 3219-3 Nut, Hex 3/8-24......................................3
45V 3247-2 Setscrew, 3/8-16 x 3/8...........................1
46 3256-14 Washer, #10 Std....................................9
47 3290-134 Screw, HH Machine 10-24 x 5/8.............1
48 3290-357 Nut, Whizlock 3/8-16 .............................6
49 3296-2 Nut, Nyloc #10-24..................................8
50 3296-29 Nut, Nyloc 5/16-18.................................5
51 3296-39 Nut, Nyloc 3/8-16...................................1
52 3296-6 Nut, Nyloc 3/8-24...................................1
53 1-303334 Washer, Spring Disk 5/16......................4
54 32128-49 Nut, Whizlock 1/2-13 .............................2
55 114439 Rivet......................................................5
56 103-9024 Decal, Commercial (42")........................1
1-403131 Decal, Commercial (48")........................1
57 106-5620 Spacer (42") ..........................................2
106-5597 Spacer (48") ..........................................2
58* 103-3460 Gearbox,(42") Std..................................1
*
103-3387 Gearbox,48 Std......................................1
59O 109-4373 Asm, Deck W/Decals (42")....................1
O
109-4372 Asm, Deck W/Decals (48")....................1
60 103-4209 Blade, LH (42") Black ............................1
103-4207 Blade, LH (48") Black ............................1
61 103-4210 Blade, RH (42") Red..............................1
103-4208 Blade, RH (48") Red..............................1
62P 103-9497 Asm, Gearbox Cover W/Decal (42") ......1
P
103-9496 Asm, Gearbox Cover W/Decal (48") ......1
63 109-4053-01 Wld, Baffle Discharge LH.......................1
64 109-4054-01 Wld, Baffle Discharge RH......................1
65 103-8626 Pad, Anti Skid (42") ...............................1
103-8629 Pad, Anti Skid (48") ...............................1
66 103-8667 Pad, Anti Skid (42") ...............................1
103-8630 Pad, Anti Skid (48") ...............................1
67 3296-42 Nut, Nyloc 1/4-20...................................4
68 3256-23 Washer, 5/16 SAE.................................3
69 1-807533 Bolt, Carriage #10-24 x 5/8....................3
70 3296-12 Nut, Nyloc #10-24 Thin..........................3
71 32148-7 Insert, Threaded 5/16-18 .......................6
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
V Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on setscrew, item #45.
O Deck assembly includes anti skid pad, item #66.
P Gearbox cover assembly includes anti skid pad, item #62.
Q Deck latch assembly includes nyloc nut, item #52.
Rear deck height adj. assembly includes (1) whizlock nut. Item #48.
* Fill gearbox sections to drain/fill plug with Mobil SHC (synthetic) 75w-90 gear lube oil.
