11 — ENG
OPERATING PROCEDURES (cont'd)
High Pressure Operation:
DO NOT let hoses come in contact with
very hot engine muffler during or immedi-
ately after use of your pressure washer.
RISK OF INJECTION OR INJURY TO
PERSON. DO NOT DIRECT DISCHARGE
STREAM TOWARD PERSONS.
WHEN USING THE HIGH PRESSURE
SETTING, DO NOT ALLOW THE JET-LIKE
SPRAY TO COME IN CONTACT WITH
UNPROTECTED SKIN, EYES, OR WITH
ANY PETS OR ANIMALS. SERIOUS
INJURY CAN OCCUR.
Multi-Reg — Pull back nozzle for high pressure—
Figure 7.
Hi-Low — Turn knob clockwise until it stops—Figure
8.
Dual Lance — Turn black handle grip clockwise until
it stops—Figure 9.
NOTE: O°, 15°, 25°, and 40° nozzles will change the
fan spray. The size of the nozzle will determine the
size of the fan spray. To change nozzles:
1. Shut off the pressure washer and turn off the
water supply.
2. Pull trigger on gun handle to relieve any water
pressure.
3. Remove the nozzle on the end of the wand.
4. Insert new nozzle and tighten securely.
Note: Be sure to teflon tape nozzle prior to
assembly. Maintain at least one thread away from
the end when applying the tape. You must wrap
teflon tape in the direction of the threads. Two
wraps only required.
Figure 8
Hi-Low
Figure 9
Dual Lance
Multi-Reg (High Pressure Setting)
Figure 7
