Cub Cadet SLT1550, SLT1554 Lawn Mower User Manual



14
Engaging the Parking Brake
To engage the parking brake:
Fully depress the brake pedal and hold it while
gently pushing the parking brake lever downward.
Hold the parking brake lever down while removing
your foot from the brake pedal.
Once engaged, the parking brake lever and the
brake pedal will lock in the “down” position.
To disengage the parking brake:
Slightly depress the brake pedal.
NOTE: The parking brake must be engaged if the
operator leaves the seat with the engine running or the
engine will automatically shut off.
Driving The Tractor
WARNING: Avoid sudden starts, ex-
cessive speed and sudden stops.
WARNING: Do not leave the seat of the
tractor without first placing the PTO/Blade
Engage knob in the disengaged (OFF)
position, depressing the brake pedal and
engaging the parking brake. If leaving the
tractor unattended, also turn the ignition key
off and remove the key.
Briefly depress the brake pedal to release the
parking brake. Move the throttle lever into the FAST
(rabbit) position.
To travel FORWARD, slowly depress the upper
portion of the drive pedal forward until the desired
speed is achieved. See Figure 6.
Figure 6
To travel in REVERSE, check that the area behind
is clear then slowly depress the lower portion of the
drive pedal with the ball of your foot (NOT your
heel) until the desired speed is achieved. See
Figure 6.
IMPORTANT:
Do NOT attempt to change the direction of
travel when the tractor is in motion. Always bring the
tractor to a complete stop before pivoting the drive
pedal from forward to reverse or vice versa.
Driving On Slopes
Refer to the SLOPE GAUGE on page 7 to help determine
slopes where you may operate the tractor safely.
WARNING: Do not mow on inclines with a
slope in excess of 15 degrees (a rise of
approximately 2-1/2 feet every 10 feet). The
tractor could overturn and cause serious
injury.
Mow up and down slopes, NEVER across.
Exercise extreme caution when changing direction
on slopes.
Watch for holes, ruts, bumps, rocks, or other
hidden objects. Uneven terrain could overturn the
machine. Tall grass can hide obstacles.
Avoid turns when driving on a slope. If a turn must
be made, turn down the slope. Turning up a slope
greatly increases the chance of a roll over.
Avoid stopping when driving up a slope. If it is
necessary to stop while driving up a slope, start up
smoothly and carefully to reduce the possibility of
flipping the tractor over backward.
Setting The Cruise Control
NOTE: The cruise control feature should only be
utilized while traveling in the forward direction.
Slowly depress the upper portion of the drive pedal
until the desired speed is achieved.
Lightly depress the cruise control lever.
While continuing to hold the cruise lever down, lift
your foot from the drive pedal (you should feel the
cruise latch engage).
Once engaged, the cruise control lever and the
drive pedal will lock in the “down” position, and the
tractor will maintain the same forward speed.
NOTE: Cruise control can not be set at the tractor’s
fastest ground speed. If the operator should attempt to
do so, the tractor will automatically decelerate to the
fastest optimal mowing ground speed.
Disengage the cruise control using one of the following
methods:
Brake Pedal
Drive Pedal
