CURVED BOOM BACKHOE
Maximum digging depth 76.5"
Digging depth (2' flat bottom) 74.5"
Swing arc 150°
Loading height (bucket at 60°) 60"
Reach from swing pivot 104"
Transport height 66"
Bucket rotation 180°
Loading reach 33"
Transport overhang 37"
Undercut 17"
Stabilizer spread (down) 74"
Bucket cylinder digging force 2,036 lbs.
Dipperstick cylinder digging force 1,187 lbs.
Weight (less bucket) 620 lbs.
Operating pressure 1,857 PSI
Ramp angle (w/industrial tires) 20.5°
Street pads Optional
Bucket options 8", 12"
RESIDENTIAL/COMMERCIAL
WARRANTY
†
Attachments 1-year limited warranty
Sc2450
MULTI-PURPOSE SUB-COMPACT TRACTOR
773-04214 Printed in U.S.A. 12/10 © 2011 Cub Cadet Yanmar
POWERTRAIN
Gross HP 24 HP* diesel
PTO HP (Hyd) 16.5 at 3,200 RPM
Rated RPM 3,200 RPM
Number of cylinders 3
Bore and stroke 72 x 74 mm
Total displacement 55.1 cu. in.
Ignition type Indirect injection
Lubrication Full pressure
Oil filter Spin-on/full flow
Cooling system Liquid cooled
Air cleaner 4" single dry
Preheat system Glow plug
Alternator 40 amp.
Exhaust Right side pointing down
CAPACITIES
Fuel tank 5.8 gal.
Cooling system 3.4 qt.
Engine oil 2.5 qt.
Transmission case 2.0 gal.
DRIVETRAIN
Transmission type Hydrostatic
Number of ranges 2 Shift-On-The-Go
®
4WD operations 2WD & 4WD selectable
Cruise control Selectable
Rear differential lock Foot pedal operation
PTO type Independent
Mid PTO/RPM (standard) 2,100/3,338
Rear PTO/RPM (standard) 540/3,111
Brake Wet disc
MAXIMUM TRAVELING SPEED
Forward low 6.0 mph
Forward high 9.3 mph
Reverse low 3.6 mph
Reverse high 5.6 mph
HYDRAULICS
Type Open center
Pump Gear/Trochoid
Steering/SCV/backhoe/3-pt hitch 3.5 GPM at 3,200 RPM
Transmission/hydraulic PTO 3.4 GPM at 3,200 RPM
Maximum pump capacity 6.9 GPM at 3,200 RPM
3-point hitch** Limited Category 1
3-point lift capacity at 24" behind 661 lbs.
Hydraulic control system Position control
DIMENSIONS
Wheelbase 55.1"
Width 44.5"
Overall length w/
loader and backhoe
172.5"
Ground clearance 7.5" (w/R4)
Weight w/ROPS & fluids 2,525 lbs.
TIRE SIZE
Front industrial/turf 18" x 8.5" – 10"
Rear industrial/turf 26" x 12.0" – 12"
RESIDENTIAL/COMMERCIAL
WARRANTY
†
Tractor 2-year or 2,000-hour limited warranty
Engine/drivetrain 5-year or 2,500-hour limited warranty
CL100 CURVED BOOM LOADER
Maximum lift height at pivot point 71"
Dump clearance 54"
Reach at maximum height 27"
Maximum dump angle 45°
Reach w/bucket on ground 40"
Maximum rollback angle 25°
Digging depth 4"
Overall height in carry position 37"
Length of attachment (bucket bottom) 19.25"
Maximum lift height under bucket 66"
Bucket width/weight 48"/125 lbs.
Bucket capacity 5 cu. ft.
Lift capacity 500 mm forward of the
pivot pins, maximum height
550 lbs.
Lift capacity at pivot pins, maximum height 700 lbs.
Breakout force at bucket pins 1,350 lbs.
Breakout force at 500 mm
forward of the pivot pins
1050 lbs.
Raising time to full height w/o load 3.5 sec.
Lowering time w/o load (power down) 2.5 sec.
Attachment rollback time 2 sec.
Attachment dumping time 1.5 sec.
Rated flow 3.5 GPM
Relief valve 1,813 PSI
Sc2450 Specifications Sc2450 Attachment Specifications
as rated by engine manufacturer
3-point hitch is optional
See your local Cub Cadet Yanmar Independent Dealer for warranty details.
