Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-729008-53100 FUEL INJECTOR 3
2 CY-129008-53000 NOZZLE ASSY 3
5 CY-114250-53080 NUT, NOZZLE CASE 3
6 CY-119802-53100 HOLDER ASSY, NOZZLE 3
10 CY-114250-53120 SPRING, NOZZLE 3
11 CY-114250-53130 SEAT, NOZZLE SPRING 3
12 CY-114250-53140 PLATE, STOP 3
13 CY-114250-53210 PIN 6
14 CY-114250-53400 SHIM PACK 3
26 CY-129150-59120 RETAINER, INJ. PIPE 2
29 CY-129150-59131 BOLT M4X14,HEX.SCKT. 4
31 CY-129004-59811 PIPE ASSY, INJECTION 1
35 CY-129004-59821 PIPE ASSY, INJECTION 1
39 CY-129004-59831 PIPE ASSY, INJECTION 1
44 CY-119802-59550 PIPE ASSY, RETURN 1
45 CY-124722-59050 CLAMP 9 2
46 CY-119802-59560 PIPE, FUEL RETURN 1
47 CY-129486-59551 PIPE, FUEL RETURN 2
48 CY-124722-59050 CLAMP 9 4
50 CY-119593-59581 CAP 1
51 CY-124060-77680 CLAMP 10 1
21
FIG. 14. FUEL SUPPLY PARTS
Copyright 2007 Cub Cadet Yanmar LLC
