ENGINE:
25 HP Kawasaki*
Make Kawasaki
Model FH721V
Horsepower 25 @ 3600 rpm
Displacement 41.2 Cu. in (675 cc)
Electrical System 12 Volt, 13 amp. Alternator, Battery: 340 CCA
Oil Capacity 2.0 US qt. ( 1.9 L) w/ Filter
26 HP Kawasaki*
Make Kawasaki
Model FX730V
Horsepower 26 @ 3600 rpm
Displacement 44.3 Cu. in (726 cc)
Electrical System 12 Volt, 15 amp. Alternator, Battery: 340 CCA
Oil Capacity 2.2 US qt. ( 2.1 L) w/ Filter
27 HP Kohler*
Make Kohler
Model CV740S
Horsepower 27 @ 3600 rpm
Displacement 44.24 Cu. in (725 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 340 CCA
Oil Capacity 2.1 US qt.. (2.0 L) w/ Filter
27 HP Kawasaki*
Make Kawasaki
Model FX751V
Horsepower 27 @ 3600 rpm
Displacement 52.0 Cu. in (852 cc)
Electrical System 12 Volt, 15 amp. Alternator, Battery: 340 CCA
Oil Capacity 2.0 US qt. ( 1.9 L) w/ Filter
28 HP Briggs & Stratton**
Make Briggs & Stratton
Model 541777-0110-E1
Horsepower 28 @ 3600 rpm
Displacement 54.88 Cu. in (896 cc)
Electrical System 12 Volt, 20 amp. Alternator, Battery: 340 CCA
Oil Capacity 2.4 qt. (2.3 L) w/ Filter
32 HP Briggs & Stratton**
Make Briggs & Stratton
Model 543777-0120-E1
Horsepower 32 @ 3600 rpm
Displacement 54.62 Cu. in (895 cc)
Electrical System 12 Volt, 20 amp. Alternator, Battery: 340 CCA
Oil Capacity 2.4 US qt.. (2.3 L) w/ Filter
CHASSIS:
Fuel Tank Capacity: 12 Gallons (45.4 L)
Rear Wheels Tire Size: 24 x 12.00 -12
Inflation Pressure: 15 psi (1,03 bar)
Front Wheels Tire Size: 13 x 6.50 - 6
Inflation Pressure: 25 psi (1,72 bar)
TRANSMISSIONS:
(S/N: 2014450933 & Below):
Hydro-Gear HGM-12E 3131 / PG-3H
(S/N: 2014450934 & Above):
Hydro-Gear TF0240LS081AAKZ (RH) / PG-3H
Hydro-Gear TF0240LS080AAKZ (LH) / PG-3H
Type Pump and Wheel Motor
Hydraulic Fluid SAE 20W-50 motor oil
Speeds Forward: 0-10 MPH (0-16.09 km/h)
@ 3400 rpm Reverse: 0-5 MPH (0-8.05 km/h)
Continuous Torque 222 ft. lbs. (301 N.m.)
Output
Maximum Weight 750 lbs. (340 Kg)
on Axle
DIMENSIONS:
Overall Length 79” (201 cm)
Overall Width 62” (157 cm)
Height 68” (173 cm)
Weight (apx..) 1175 lbs. (534 kg)
NOTE: Specifications are correct at time of printing and are subject to change without notice.
*Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors.
Specifications
**Engine Power Rating Information
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engineers)
code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and corrected in
accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM; horsepower values are derived at
3600 RPM. Actual gross engine power will be lower and is affected by, among other things, ambient operating conditions
and engine-to-engine variability. Given both the wide array of products on which engines are placed and the variety of
environmental issues applicable to operating the equipment, the gas engine will not develop the rated gross power when used
in a given piece of power equipment (actual “on-site” or net power). This difference is due to a variety of factors including,
but not limited to, accessories (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations,
ambient operating conditions (temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and
capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine.
