PARTSLIST
BOOM ANDTRIMMER PARTS - MODEL BL250
2-CYCLE PETROL TRIMMER/BRUSHCUTTER
Item Part No.
1 791-00040
2 791-00041
3 791-182690
4 791-00042
5 791-182405
6 791-180863
7 791-147346
8 791-180858
9 791-610327
10 753-04469
11 753-04103
12 791-612831
13 791-612021
14 753-04096
15 753-04097
16 791-182519
17 791-683295
18 791-181811
19 791-181812
20 791-181813
21 791-181814
22 791-181815
23 791-182816
24 791-181817
25 791-182200
26 791-182193
27 791-182195
28 791-147492
29 791-182196
30 791-683304
31 7911-683299
32 791-682061
33 791-147490
34 791-612483
35 791-683301
36 791-612026
37 791-610636B
38 791-147495
39 791-180814B
40 791-145873B
41 791-181699
* 791-160196
Description
Throttle Housing & Trigger
Assm (includes 2-4)
Throttle Trigger Lock-Out
Throttle Trigger Spring
Throttle Trigger
Switch Assembly
Wire Cover lft
Wire Tie
Foam Grip & Cover
Harness Clip
Upper Drive Shaft Housing Assembly
Bullhorn Handle Assembly
(includes 12-16)
Grip
Plug
Adapter
Cap
Anti-Rotation Screw
Handle Bracket Assembly
(includes 16 & 18-22)
Screw
Upper Handle Clamp
Middle Handle Clamp
Lower Handle Clamp
Nut
Throttle Cable
Flexible Drive Shaft
Shield Mount Screw Assembly
2 Piece Gearbox Assembly
(includes 16, 25, 27 & 29)
Gear Box Screw
Blade Shield/Shield Mount
Blade Driver
Shield Mounting Screw
Shield and Blade Assembly
(includes 32)
Blade Assembly
Retaining Washer
Spool Shaft
Outer Spool & Eyelet Assembly
Retainer
Spring
Inner Reel
Bump Head Knob Assembly
4-Tooth Blade
Nut
Shoulder Harness
@@i
2 Piece Gearbox Assembly Parts - Item 26
42 791-182191 Left Housing
43 791-182192 Right Housing
44 791-182194 Pinion Gear Assembly
45 791-182199 Output Shaft Bushing
46 791-182198 Output Shaft Gear
47 791-182197 Output Shaft Assembly (includes 45 & 46)
48 753-04348 Palnut
* 791-180014B Blade Retaining Kit (includes 33 & 41)
* 791-613226 Locking Rod Tool
Optional Accessories
* 791-180120 Replacement Line, 0.095 Diameter
* 791-147345B Reel and Line Assembly
* 791-147498B Bump Head Assembly (includes 34-39)
* Items Not Shown
23
