6. Snap the hub cap back on, and power the tool on. In a few
seconds or less youʼll hear the nylon line being cut automatically
to the proper length.
OPTION 1: ACCESSORY REPLACEMENT SPOOL
Use Black & Decker replacement spool Model No. AF-100. Discard
old spool.
OPTION 2: REWINDING SPOOL USING BULK LINE
Bulk line for your trimmer/edger is available at extra cost from your
local dealer or Black & Decker Service Center. To install bulk line,
follow the steps below. (Use .065 in. diameter ROUND line only)
1. Insert one end of the bulk line into
the hole in the spool as shown
in Figure 12 about 1/2 in. (12 mm).
2. Hold the line in the hole and pull
the rest of the line through the slot
in the spool, shown in Figure 12.
3. Snugly and evenly wind the bulk
line onto the spool in the direction
of the arrow on the spool until the
line builds up to the notches in the
spool rim. (Figure 12) Do not
overfill spool. The spool holds
30 feet (10 m) of line.
MAINTENANCE
1. Keep the air intake slots (Figure 1) clean to avoid overheating.
2. Your trimmer line can dry out over time. To keep your line in top
condition, store spare pre-wound spools or bulk line in a plastic,
sealable bag with a tablespoon of water.
3. Plastic parts may be cleaned by using a mild soap and a damp
rag.
12
4. DO NOT immerse tool in water or squirt it with a hose. DO NOT
allow any liquid to get inside it.
5. Do not store the tool on or adjacent to fertilizers, gasoline, or
other chemicals.
6. DO NOT clean with a pressure washer.
7. The line cutter on the edge of the guard can dull over time. It is
recommended you periodically touch-up the sharpness of the
blade with a file.
IMPORTANT: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment should be performed by
authorized service centers or other qualified service organizations,
always using identical replacement parts.
ACCESSORIES
Use Black & Decker replacement spool Model No. AF-100.
Reload nylon line (either bulk or prewound replacement spool) as
shown in this manual.
• USE ONLY .065 in. (1.65 mm) DIAMETER NYLON
MONOFILAMENT LINE. Do not use
serrated or heavier gauge line, as they will overload the motor and
cause overheating. The unit only functions properly with 0.065 in.
diameter nylon monofilament line. This line is available at your
local dealer or authorized service center.
WARNING: The use of any accessory not recommended by
Black & Decker for use with this tool could be hazardous.
