Part No 360314 Form No F031708A
19
AE Owner’s Manual
PARTS LIST AE
44 SCREWCAP 3/8 -16 x1 8041050 2 8041050 2 8041050 2 8041050 2
49 FLAT WASHER 1/2" 8171006 4 8171006 4 8171006 4 8171006 4
50 NUT LOCK 5/16-18 8160002 55 8160002 68 8160002 55 8160002 55
55 CABLE CLUTCH ASSY 360313 1 360313 1 360313 1 360313 1
59 SPACER TINE SPROCKET END 360108 1 - - 360108 1 360108 1
60 PULLEY ENGINE 610417 1 610417 1 610417 1 610417 1
61 SPROCKET 42 T 360106 1 360106 1 360106 1 360106 1
62 SPACER - TINE SPROCKET 1.468 360272 3 360107 3 360272 3 360272 3
63 SCREW CAP 5/16-18 x 2.50" 8041034 3 - - 8041034 3 8041034 3
SCREWCAP 5/16-18 X 1 3/4" HCS ZP - - 8041031 3 - - - -
64 TINE PLATE 360101 8 360101 10 360101 8 360101 8
65 TINE 360100 24 360100 30 360100 24 360100 24
66 SPACER - NUT RIGHT END 360266 1 360282 1 360266 1 360266 1
67 SPACER - BETWEEN TINE ASSEMBLIES 360265 3 360104 4 360265 3 360265 3
69 HEAVY WASHER TINE ASSY 830113 1 830113 1 830113 1 830113 1
70 WASHER LOCK 7/8" INTERNAL 350154 1 350154 1 350154 1 350154 1
71 NUT JAM 7/8 -14 (Torque 100 ft.lbs) 350155 1 350155 1 350155 1 350155 1
72 CARRIAGE BOLT 5/16-18X1.75 8024043 48 8024043 60 8024043 48 8024043 48
73 SHAFT TINE DRIVE 360102 1 360102 1 360102 1 360102 1
74 SCREW CAP 5/16 - 18 x 1.5" 8041030 4 8041030 4 8041030 4 8041030 4
75 WASHER FLAT CUT 5/16 8171003 9 OR 10 8171003 9 OR 10 8171003 9 OR 10 8171003 9 OR 10
77 LABEL HOT ENGINE 400268 1 400268 1 400268 1 400268 1
78 LABEL DANGER GUARD 900327 2 900327 2 900327 2 900327 2
80 NUT LOCK 1/2 -13 THIN 8161044 2 8161044 2 8161044 2 8161044 2
81 SPACER BEARING/SPROCKET 0.375 THK 360109 1 360109 1 360109 1 360109 1
90 ENGINE 360127 1 360278 1 360278 1 360306 1
94 LOCKNUT 3/8" - 16 THIN HGT 8161042 1 8161042 1 8161042 1 8161042 1
106
WASHER 1.062" ID X 1.75 OD 8172021 4 OR 5 8172021 4 OR 5 8172021 4 OR 5 8172021 4 OR 5
108
CHAIN MASTER LINK 360205 2 360205 2 360205 2 360205 2
119
SPACER - TINE PLATES 360105 4 360105 5 360105 4 360105 4
120
TINE ASSY (INCLUDES 50,64,65,72,&119) 360197 1 360197 1 360197 1 360197 1
121
RUBBER PAD 1/8" TK X 1/2" W 350310 1 350310 1 350310 1 350310 1
ITEM AE401 AE401H5T AE401H AE401S
NO.
Part No. Part No. Part No. Part No.
1 FRAME ASSEMBLY WA AE401 360304 1 360304 1 360304 1 360304 1
4 BEARING 3/4" PILLOW BLOCK 350133 4 350133 4 350133 4 350133 4
5 SCREWCAP 3/8-16 x 1 1/2 8041052 12 8041052 8 8041052 12 8041052 12
SCREWCAP 3/8-16 x 1 1/4" - - 8041051 4 - - - -
6 FRONT AXLE ASSY 360332 1 360332 1 360332 1 360332 1
7 KEY SQUARE 3/16 x 3/16 x 1.25 9201080 3 9201080 3 9201080 3 9201080 3
8 WHEEL 10.5" SEMI PN. W3/4" KEYED HUB 360388 2 360388 2 360388 2 360388 2
9 FENDER WASHER 5/16" 8172020 3 8172020 3 8172020 3 8172020 3
10 WASHER LOCK 5/16 TWISTED TOOTH 430298 2 430298 2 430298 2 430298 2
11 SCREWCAP 5/16-18 x 1" 8041028 2 8041028 2 8041028 2 8041028 2
12 GUARD DIFFERENTIAL AE 360248 1 360248 1 360248 1 360248 1
13 SCREW SELF TAP 1/4 x 1/2" 8122080 2 8122080 2 8122080 2 8122080 2
14 JACKSHAFT AERATOR ASSY 360331 1 360331 1 360331 1 360331 1
15 BEARING 1" PILLOW BLOCK 810700 2 810700 2 810700 2 810700 2
16 NUT LOCK 3/8-16 8160003 16 8160003 15 8160003 16 8160003 16
20 BELT 4L x 43" POWER RATED 360120 1 360120 1 360120 1 360120 1
21 CHAIN #40 x 94 PITCH O-RING (WHEEL) 360115 1 360115 1 360115 1 360115 1
22 CHAIN #40 x 76 PITCH O-RING (TINE) 360114 1 360114 1 360114 1 360114 1
23 PULLEY IDLER 4.5" 500270 1 500270 1 500270 1 500270 1
24 ARM IDLER WA 510199 1 510199 1 510199 1 510199 1
25 BRACKET MOUNT IDLER 360121 1 360121 1 360121 1 360121 1
26 BELT FINGER FRONT AE 360219 1 360219 1 360219 1 360219 1
27
28 BOLT SHOULDER 1/2 x 1 500114 1 500114 1 500114 1 500114 1
29 SPROCKET IDLER 17T x 5/8" BORE 360116 2 360116 2 360116 2 360116 2
30 SPACER SPROCKET IDLER 2.5" 360123 1 360123 1 360123 1 360123 1
31 SCREW CAP 1/2 - 13 x 4 8041106 1 8041106 1 8041106 1 8041106 1
32 SPACER SPROCKET IDLER 1.175" 360124 1 360124 1 360124 1 360124 1
33 SCREW CAP 1/2 - 13 x 3" 8041102 1 8041102 1 8041102 1 8041102 1
43 WASHER FLAT 3/8 SAE 8172009 12 8172009 12 8172009 12 8172009 12
DESCRIPTION QTY QTYQTYQTY
