60 IN ROTARY - HEAD SUB-ASY (SWIVEL MNT)
Continued...
ITEM PART NO. QTY. DESCRIPTION
02983207 1 60" HEAD SUB-ASY, W/ OPT SWIVEL MOUNT
1 02981410 1 DECK WELDMENT
2 02981752 1 PLATE, HITCH POST BOTTOM
3 02981820 28 BOLT, SOCKET HEAD 1/2"-NC X 1-1/2" PL GR8
4 02981318 1 SLEWING BEARING
5 02981741 1 HITCH POST WELDMENT, (OPT SWIVEL MOUNT)
6 02892100 8 BOLT, HEX HEAD 3/4"-NC X 1-3/4" PL GR5
7 00037200 16 LOCKNUT, 3/4"-NC PLC
8 02968859A 1 SPINDLE HOUSING ASY, SPLINED SHAFT
9 5312316 16 WASHER, (SPECIAL)
10 02966899 2 SKID SHOE
11 02969230 1 BLADE BAR ASY, W/ BLADES
12 02964861 4 BOLT, SOCKET HEAD 3/4"-NC X 4" PL GR8
13 00003901 4 LOCKWASHER, 3/4" PL HEAVY
14 00059700 14 BOLT, FLAT SOCKET HEAD 3/8"-NC X 1-1/4"
15 00015800 14 LOCKNUT, 3/8"-NC PLB
16 15B600 14 WASHER, 3/8" SAE P
17 02961747 1 MOTOR ASY, CAST IRON W/ SPLINED SHAFT
18 00019600 4 LOCKWASHER, 1/2" HEAVY
19 02891800 4 BOLT, HEX HEAD 1/2"-NC X 1-3/4" PL GR8
20 02961038 1 GASKET, SPINDLE TO MOTOR
21 03200269 8 BOLT, HEX HEAD 3/4"-NC X 3" PL GR8
22 00749101 2 SPLIT FLANGE KIT, 1-1/2"
23 02962774 2 ADAPTER, HYD ELBOW
©2008 Alamo Group Inc. Parts Section -26
Axtreme Boom 18-22-25 ft (08-06) Rev 09-08
