48 IN FLAIL - HEAD ASY (SWIVEL MNT) (PART 1)
Continued...
ITEM PART NO. QTY. DESCRIPTION
1 02970301 1 WLDMT, FLAIL AXE HEAD
2 02957655M 1 ASY, CUTTERSHAFT, 48" F/A
3 02970465 1 WLDMT DOOR, 48" FLAIL AXE
4 02973544 1 WLDMT, MOTOR MOUNT
5 02970709 1 PLATE, COVER FLAIL AXE
6 10119000 2 HHCS 5/16 NC 1 PL5
7 00023500 6 FLATWASHER 5/16, TYPE AW, ZP
8 00750940 2 NUT, TOPLOCK 5/16 NC PL B
9 02958131A 2 FLANG BEARING ASY
10 02956714 1 CLAMP BAR
11 02956712 1 RUBBER FLAP
12 02970326 1 ROD-HINGE, F/A DOOR
13 02958198 1 1/2 X 1/2 X 1 7/8 LG
14 02970585 1 WLDM SKIDSHOE INSIDE FLAIL AXE
15 02956748 1 SKID SHOE WLDMT
16 02970540 1 WLDMT - REAR ROLLER
17 02967325 2 PULLEY, 3G5V - 8.50 DIA
18 02970325 1 PLATE-BELT & PULLEY COVER
19 02972442 1 FLAIL AXE BEARING GUARD
20 02675800 2 HHCS 5/8 X 1-1/2 PL GR5
21 00010300 2 LOCKWASHER 5/8
22 00001400 4 FLATWASHER 5/8 PL STD
23 00019300 8 HHCS 1/2 X 1-1/2 NF GR5 PL
24 000642 8 LOCKNUT TLM 1/2 NC PLB
25 00752670 1 GREASE FITTING 1/4-28 BOLT THD
26 00008300 6 BOLT, HHCS 5/8" NC X 1-3/4" PL5
27 00695100 5 LOCKNUT TOPLOCK 5/8NC PLB
28 02970710A 1 CYL, DOOR, 48" F/A
29 02970324 1 PLATE-CLAMP, HITCHPOST
30 000941 1 GREASE ZERK 1/4-28 90 BOLT THD
31 02970583 4 SHCS 3/8 NF 1-1/2 PL GR5
32 23504500 8 JAMNUT 3/8 NF
33 03200925 1 CARR 5/8 NC X 3 PL GR5
34 02967328 1 BUSHIN, QD HUB SF 1-15/16 ID
35 02970537 1 BUSHING, QD HUB SF 1 ID
36 00013500 3 NUT, 3/8 NC JAMNUT
37 02970539 3 V BELT
38 02956768 2 PIN, ROLL 5/32X1
39 00011700 4 LOCKWASHER 5/16 PL STD
40 00035900 4 HHCS 5/16 NC X 3/4 GR5
