Series 80PLUS Operator’s Guide
PRINT SPEEDS
TEXT (6 lpi) TEXT (8 lpi) GRAPHICS POWER SUPPLY
31.8 lps 42.5 lps 5.3 in/s
(135 mm/s)
48 watts
(minimum required)
!
The following features and items are standard on all Series 80PLUS Printers
♦ 44-column printing at 15.6 characters per inch
♦ 4.0-inch (100-mm) diameter thermal paper roll
♦ 420 feet (128 m) of thermal paper per roll
♦ Automatic cutter (partial cut)
♦ Easy paper load
♦ High resolution graphics capability (8 dots per mm)
♦ RS-232C serial interface with adjustable buffer (8K default)
♦ Epson TM-T8x, Axiohm 7193, M50, or 80PLUS emulation
♦ Paper out sensor
♦ Operator controlled self-test
♦ Dual cash drawer connectors (RJ11) and drivers (24V, 1.2 amp
pulse for approximately 150 ms; drawer open/closed status reporting)
