Pin Assignment
Satellite U400/Satellite Pro U400/PORTEGE M800 Maintenance Manual 29
177 +3V --- 178 EXT_HDMITX1P O
179 +3V --- 180 GND ---
181 +3V --- 182 EXT_HDMITX0N O
183 NC --- 184 EXT_HDMITX0P O
185 GND --- 186 GND ---
187 NC --- 188 NC ---
189 VIN_VGA --- 190 VIN_VGA ---
191 VIN --- 192 VIN ---
193 VIN --- 194 VIN ---
195 VIN --- 196 VIN ---
197 VIN --- 198 VIN ---
199 VIN --- 200 VIN ---
CN32 1394 connector
P/N:DFHS04FR109 CONN DIP 1394 4P FR(P0.8,H6.6)
PIN No. Signal name I/O PIN No. Signal name I/O
1 L1394_TPB0- O 2 L1394_TPB0+ O
3 L1394_TPA0- O 4 L1394_TPA0+ O
5 GND --- 6 GND ---
7 GND --- 8 GND ---
CN33 External MIC jack connector
