X6DH8-G2/X6DHE-G2 User's Manual
SCSI Enable/Disable
(*ForX6DH8 only)
Jumper JPA1 allows you to enable
or disable the SCSIheaders.
Jumper JPA1 is for headers #1 and
#2. The default setting is pins 1-2
to enable all four headers. See the
table on the right for jumper set-
tings.
Jumper
Position
Pins 1-2
Pins 2-3
Definition
Enabled
Disabled
SCSI Enable/Disable
Jumper Settings
(JPA1)
SCSI CH A/B Termination
Enable/Disable (*ForX6DH8
only)
Jumpers JPA2 and JPA3 allow you
to enable or disable termination for
the SCSI connectors. Jumper JPA2
controls SCSI channel A and JPA3
is for SCSI channel B. The default
setting is open to enable (terminate)
both SCSI channels. (*Note: the
manufacture default setting is
"Open". For SCSI to function
properly, please do not change
the default setting.) See the
table on the right for jumper set-
tings.
Jumper
Position
Open
Closed
Definition
Enabled
Disabled
SCSI Channel Terminatio
Enable/Disable
Jumper Settings
(JPA2, JPA3)
