To install and use the SCC-C6407, the following cables should be
prepared.
Power Adapter Cable
The cable that plugs into the SCC-C6407 power input receptacle has the
rated voltage of AC24V, 1.5A.
Check the rated voltage before using the cable.
Video Cable
The SCC-C6407's cable is a BNC Cable for connecting the video-output
terminal to the video-input terminal of the monitor.
Preparing the Cables
2-3
E
2-2
SCC-C6407
Bracket anchor
Camera Holder
Adapter Board
Cover Body
Owners
Instructions
Screws
Before Installing
Checking Package Contents
Please check that all components listed below are included in the package:
