4
FIGURE 1
CROSSOVER INSTA L L A T I O N
FIGURE 2
DRIVER INSTA L L AT I O N
FA C T O R Y LOCAT I O N
FIGURE 3
DRIVER INSTA L L A T I O N
SUPPLIED SPACER RING
FIGURE 4
DRIVER INSTA L L AT I O N
SUPPLIED GRILLE
(IF ADDITIONAL CLEARANCE IS REQUIRED
USE TWO SPACER RINGS.)
Seating The Driver
& Spacer Ring:
When the screw holes on the adapter ring/spacer line up with
the holes on the driver’s basket, you will hear and feel them
“click” into place.
WA R N I N G :
CROSSOVER IS NOT WAT E R P R O O F. DO
NOT INSTALL IN AREAS OF POTENTIAL
WATER EXPOSURE. THIS IS NOT COVERED
UNDER MANUFACTURER’S WA R R A N T Y.
