generator base. Use a deflector (piece of cardboard
or paper) to direct the oil down the hole.
GENERATOR CARE
The generator is a two pole, 3600 RPM, 60 Hz,
brushless, revolving field and synchronous type with
one sealed radial roller bearing. The generator
rotor is directly connected to the engine crank shaft,
and the stator is rigidly coupled to the engine
casting via the generator adapter casting.
Exercising The Generator - The generator
should be operated every three to four weeks.
Warm the unit up by starting the engine and letting
it run for 10 to 15 minutes. This will dry out any
moisture that has accumulated in the windings. If
left, this moisture can cause corrosion in the
winding. Frequent operation of the
engine/generator will also ensure that the set is
operating properly should it be needed in an
emergency.
Generator Maintenance - The generator head
is brushless and maintenance free. Any major
generator service including the installation or
replacement of parts should be performed only by a
qualified electrical service technician. USE ONLY
FACTORY APPROVED REPAIR PARTS. Obtain
factory parts from Customer Service at 1-800-270-
0810.
A. Bearing - The bearing used in the generators
is a heavy duty sealed roller bearing, requires no
maintenance or lubrication.
B. Receptacles - Quality receptacles have been
utilized. If a receptacle should become cracked or
otherwise damaged, replace it. Using cracked or
damaged receptacles can be both dangerous to the
operator and destructive to the equipment.
ENGINE FUEL LINE BLEEDING
If the engine is having difficulty in starting and
the fuel and oil levels are acceptable, the problem
can usually be traced to air bubbles trapped in the
fuel line.
To bleed air from the fuel line:
1: Allow engine to cool down.
2: Turn the fuel valve to the OFF position.
3: Loosen the hose clamp on the fuel line.
4: Pull the fuel line off of the fuel injector.
5: Turn the fuel valve to the ON position
6: Allow fuel to drip from the fuel line into a
small container.
7. Reattach the fuel line to the fuel injector.
WARNING, Stand-by Operation
If your generator is to be used as a standby
electric power source in case of utility failure, it
must be installed by a registered and licensed
electrician and in compliance with all applicable
state and local electrical codes. Also, local Fire
Departments must be consulted concerning proper
and safe handling procedures for gasoline. NEVER
connect any generator to any existing electrical
system without an isolating, UL approved transfer
switch, installed by a licensed electrician.
