Edge blending
• High bit-depth blending up to 20% of the
image width on all four sides of the DMD
(approximately 800 pixels overlap per edge)
• Black level adjustment of the blended area
to create different overlap areas
• Correction for non-active pixels at the edge
of the display
Video & Graphics Processing
• Up to 60fps 4096 x 2160 pixels sequential input via single cable (Display
Port 1.2)
• Dual Pipe input capability (2 x Display Port 1.2)
• 3D Capable
• Scaling of HDMI formats to fill the 4k display
• HDMI for Side by Side, Frame Packing & Top Bottom Formats
• Dual Flash Processing can be used to multiply the displayed frame rate for
3D sources (example 144Hz display)
• Two sources in parallel for Left and Right Eyes
Image Blanking
• Linear black “curtains” adjustable for all four edges
Color adjustments
• Up to 12 bits per color processing
(depending on source and input type)
• Degamma table maps 12 bit input to 16 bit palette
(R, G & B) for display
• Individual R, G & B gain and bias controls
Powerful 3-chip 1.38” DLP installation projector with
laser-phosphor light source supports
new, demanding projection applications
Projector Control
• Keypad with
LCD panel
• Network control
via RJ45 and
protocol
• Group Controller
Application
3D Functionality
• Full 4k 3D display capability
• Dual Pipe: Left and Right channels input
separately to projector in parallel, then
interleaved for sequential display
• Synchronization of active glasses
• Adjustable Dark Time and Sync Offset
for optimization of ghosting and smooth
grayscale for switching switching glasses
and polarizers
• HDMI input signals will be scaled to the
DMD resolution.
NP-PH1201QL
