E-45
PC Control Command Reference
Command Codes
No. Function Code Data Description
01 Video 03H No Same as remote
02 RGB1 04H No Same as remote
03 RGB2 05H No Same as remote
04 S-VIDEO C6H No Same as remote
05 PC CARD 27H No Same as remote (available only when the Viewer board is installed)
06 Power On 08H No Same as remote (See NOTE on page E-46)
07 Power Off 14H No Same as remote
08 Picture Mute 47H No Same as remote
09 Onscreen Mute 11H No
10 Power Zoom W 09H No Same as remote
11 Power Zoom T 0AH No Same as remote
12 Power Focus + 0BH No Same as remote
13 Power Focus – 0CH No Same as remote
14 Reset 43H No (Resets immediately after returning ACK)
15 Freeze 4CH No Same as remote
16 Slide + 4BH No Same as remote (available only whenPC CARD is selected)
17 Slide - 20H No Same as remote (available only whenPC CARD is selected)
18 Front Floor 33H No
19 Front Ceiling 34H No
20 Rear Floor 35H No
21 Rear Ceiling 36H No
22 Auto Start On 19H No
23 Auto Start Off 1AH No
24 Image mode Select 1EH Yes 0 to 2 at Video, 3 to 5 at the others
25 Power Management On 15H No
26 Power Management Off 16H No
27 Brightness 60H Yes 0 to 63
28 Contrast 62H Yes 0 to 63
29 Color 64H Yes 0 to 63
30 Tint 66H Yes -32 to +31(E0 to 1F)
31 Sharpness 68H Yes 0 to 3
32 Audio Volume 6AH Yes 0 to 63
33 Picture Adj 70H Yes* 768 to 1279 (2 byte code)
34 Fine Picture 6EH Yes 0 to 31
35 H Position 72H Yes -64 to +63 (C0 to 3F)
36 V Position 74H Yes -32 to +31 (E0 to 1F)
37 Lamp Reset 3FH No
38 Language Select 3DH Yes 00:English, 01:German, 02:French, 03:Italian, 04:Spanish, 05:Swedish
39 White Balance
Sub Brightness R 75 Yes 0 to 7FH
G 76 Yes 0 to 7FH
B 77 Yes 0 to 7FH
Sub Contrast R 78 Yes 0 to 7FH
G 79 Yes 0 to 7FH
B 7A Yes 0 to 7FH
40 Pointer Select 7F Yes 0 to 7
41 Video System 61 Yes 0 to 2 (available only when VIDEO is selected)
These commands are subject to change without notice.
*(Low-order data) (High-order data) CSUM
CSUM = Checksum is a low-order digit of the sum from the Code to the immediately preceding data.
