OPTICAL
LCD Panel 1.0” p-Si TFT w/ MLA
Resolution 1024x768 pixels up to UXGA with Advanced AccuBlend
Lens
Power zoom and Power AUTO focus F=1.74-2.18, f=30.8-41.6mm
Light Output
3400/2700 normal/eco
(ANSI, typical)
Optional Extended
1900 super-eco
life lamp
Lamp 275W/220W/160W NSH, normal/eco/extended
Lamp Life Optional Extended lamp 4000H
(up to)
Standard lamp Eco-mode 3000H; Normal mode 2000H
Contrast Ratio
800:1
Image Size 25 - 500 inches diagonal
Keystone Cor
rection ±40 degree (Vertical), ±35 degree (Horizontal)
Pr
ojection Distance 2.46-68.9ft, 0.75-21m
Projection Angle TELE: 10.3 – 10.7 degree; WIDE: 13.7 – 14.4 degree
ELECTRICAL
Inputs
1 DVI-D, 1 5-BNC, 1 RGB, 1 S-Video, 1 Video, 2 PC Card, 2 L/R RCA Audio, 3 Stereo Mini
Audio, 1 USB A, 1 Remote
Outputs
1 RGB, 1 Stereo Mini Audio, 1 L/R RCA Audio, 1 USB B, 1 9-Pin PC Control, 1 Mouse
V
ideo Compatibility NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, SECAM, HDTV: 1080p, 1080i, 720p,
SDTV: 480p, 480i (w/optional cable), Y/Cb/Cr component (w/optional cable)
Scan Rate
Horizontal: 15 to 100 kHz (non-interlaced) Vertical: 48 to 120 Hz
V
ideo Bandwidth RGB 80MHz
Pixel Clock Freq 102MHz
Color Reproduction 16.7 million colors simultaneously, Full color
Horizontal Resolution
NTSC, NTSC4.43, PAL/PAL-M/PAL-N/PAL-60 - 600TV lines
S-video (NTSC/PAL) – 650TV lines
SECAM - 350TV lines, Y/Cb/Cr - 800TV lines,
RGB -1024dots (H) x 768dots (V)
Exter
nal Control RS232, USB, LAN, IR, (AMX/Crestron compatibility)
Sync Compatibility Separate Sync / Composite Sync / Sync on G
Built-in Speakers 5Wx2 with volume, bass, treble control
Fan Noise Normal mode <39
Eco-Mode <34
Super Eco-Mode <29
Power Requirements 100-120VAC/200-240VAC, 50/60Hz
Input Current 4A (100-120VAC), 2A (200-240VAC)
Power Consumption 390W
MECHANICAL
Installation Orientation: Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
Dimensions (WxDxH) 13.15x12.72x4.53, 334x323x115mm (Not including protrusions)
Net Weight 13.lb. (5.9 Kg)
Environment Operational Temp. 32° to 95°F / 0° to 35°C
Humidity: 20-80% non-condensing
Storage: 14° to 122°F / -10° to 50°C
Regulations USA UL 60950 FCC Class B
Canada CSA60950 (C-UL)
Accessories Users manual, wired/wireless addressable remote control with laser pointer, power cable,
remote cable, signal cable, quick connect guide, registration card, application CD-ROM
Warranty Registered owners receive a 2-year limited, parts and labor warranty including InstaCare.
InstaCare provides the original owner either limited 3 business day repair/return or next
business day exchange. The lamp when used
under nor
mal operating conditions is cover
ed
for 500 hours or 3 months, whichever comes first.
BUIL
T-IN IMAGE SENSOR ENABLES
Auto Focus lens Automatically have the projector focus to the screen. Allows for the use of multiple screens
and easily switch between them with minimal user inter
face
Automatic Wall Provides for true color reproduction when projecting onto non-
Color Correction standard screens or colored walls
Automatic 3D Refor
m Horizontal, vertical and diagonal keystone correction
PRODUCT/ACCESSORIES
Or
der Code
Description
MT1075 MT1075, XGA, 4200 ANSI projector
MT1065 MT1065, XGA, 3400 ANSI projector
MT60-10RL
1:1 Shor
t thr
ow lens, MT1075, MT60 Series
MT60-26ZL 2.7-4.2:1 power zoom and power focus lens, MT1075, MT60 series
MT70LP Replacement lamp for MT1075
MT60LP
Replacement lamp for MT60 series
MT60LPS Optional Extended life lamp for MT1075, MT60 Series
MT60CM Ceiling mount kit MT1075, MT60 Series
MT60TC
Local transpor
t/storage case w/wheels for MT1075, MT60 Series
MT60ATA ATA shipping case for MT1075, MT60 Series
SWL-2100N Wireless network card
WARRANTY OPTIONS
Order Code Description
VLMPL-01 1 year limited parts and labor extension
VLMIC-01 2nd year limited InstaCare coverage
VLMIC-02 3rd year limited extended warranty plus 2nd and 3rd year limited InstaCare coverage
VLMTC-02 For duration of the standard warranty (2 years), loaner or repair services are available in EU
countries, Japan, and Australia (for U.S. and Canadian residents traveling abroad)
ADDITIONAL FEATURES
Wireless or Wired With optional network cards, access your projector to handle
Networking
remote diagnostics or provide for real time display. Also,
pr
ovides email notification selection.
Government ADA508 closed caption and black/white menu settings and
Compliance Executive Order 13221 less than 1W standby power consumption
Security
• User can enable projector to become inoperable if keyword or
Enhancements PCMCIA card are not input.
• Cabinet Control Panel Lock–lock cabinet control keys to prevent
unauthorized access and adjustments
•
Password protected–Logo and menu enable to further eliminate
unauthorized use
• Kensington Lock slot
Geometric Cor
rection Display a square image on cylinder or spherical screen or at 90° corner
Utility shots
VORTEX Technology Provides uncompromising display of video and data. Improves white
Plus™
level, color accuracy, dynamic range, and display of varying levels of
black in an image. Color correction system enables six-axis adjustment
of CMY and RGB for display of personal color preferences
Eco-Mode™ Increase lamp life through light output adjustments and provides for
total cost of ownership
Long life Lamp Optional long life lamp provides for up to 4,000 hours of lamp life
that enables best cost of operation
Sleep Timer Timer can be set to automatically turn off the projector at selected
intervals up to 16 hours
Advanced AccuBlend™ Ensures detailed images when non-native resolution sources
are connected to the projector
AutoSense™ Automatic set-up and one touch adjustments for ease of use
Built-in Presentation Download your presentation onto a PC Card and present
Viewer directly from the projector
Image magnification
64-step magnification with location contr
ol
Chalkboard/ When a USB mouse is connected the presenter can make on
USB input
scr
een annotations
Everything should be this easy
MT1065 installation projector.
4.53”
(115mm)
13.15”
(334mm)
12.72”
(323mm)
