This section provides technical information about the MultiSync MT1000 LCD Projector's performance.
Optical
LCD Panel
1.3", p-Si TFT active-matrix, 1024ן768 dots
Lens Power zoom, power focus
F 2.5 f =52 – 68 mm
Lamp Metal halide lamp 250 W
(Guaranteed life span: 2,000 hours or
6 months from date of purchase,
whichever comes first.)
Image Size 20-300 inches diagonal
Projection Distance 3.28 – 40.03 ft (1.0 – 12.2 m)
Light Output 450 ANSI lumens
Contrast Ratio Greater than 200 : 1
Color Temperature 8,500 ± 1500 Kelvin
SPECIFICATIONS6
Electrical
Inputs Video (NTSC / PAL / SECAM / NTSC4.43)
RGB (H : 15 – 85 kHz, V : 50 – 85 Hz)
Video Bandwidth 80 MHz
Color Reproduction Full color, 16.7 million colors simultaneously.
Horizontal Resolution 550 TV lines: NTSC, 350TV lines: PAL / SECAM / NTSC 4.43
RGB 1024 dots horizontal, 768 dots vertical
Power Requirement 100 – 120 / 220 – 240 VAC, 50 / 60 Hz
Input Current 5.8 A
Mechanical
Dimensions 15.4" (W)ן5.8" (H)ן12.7" (D)
39.0 cm (W)ן14.5 cm (H)ן32.1 cm (D)
Net Weight 15.9 lbs / /7.2 kg
Operational Temperatures LCD projector: 32° – 104°F(0° to 40°C), 20 – 80% humidity
Remote control: 32° – 140°F (0° to 60°C)
Remote mouse receiver: 32° – 140°F (0° to 60°C)
Regulations UL Approved (UL 1950, CSA 950)
Meets DOC Canada requirements
Meets FCC Class A requirements
