RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg15352
(S/N 223259-)WLDMT. WING AXLE LH.318-011H1.
(S/N 223259-)WLDMT. WING AXLE RH.318-010H2.
NUT HEX TOP LOCK 1-8 PLT803-168C3.
HHCS 1-8X6 GR5802-357C4.
HUB GREASE CAP200-001D5.
NUT HEX SLOTTED 7/8-14 PLT803-029C6.
WASHER SPINDLE - 7/8804-055C7.
BEARING CONE 15123822-091C8.
Rev. 3(S/N 414628+) W/CUPS, ZERK &
STUDS
HUB 4 BLT W/CUPS, ZERK & STUDS815-230C9.
Rev. 2(S/N 414627-) W/CUPS & ZERKHUB 4 BOLT WHL W/CUPS & ZERK815-093C9.
Rev 1; Use up stock4 BLT WHL HUB W/CUPS&ZERK ASSY312-151S9.
SEAL 1 3/8 ID X 2.441 OD X.313816-098C10.
PIN COTTER 3/16 X 1 1/4 PLT805-016C11.
Use with #16, 17 & 18 S/N 414627-WASHER FLAT 1/2 SAE PLT804-016C12.
Use with #16, 17 & 18 S/N 414627-WASHER LOCK SPRING 1/2 PLT804-015C13.
Use with #16, 17 & 18 S/N 336501
to 414627
HHCS 1/2-20X1 1/4 GR5802-326C14.
Use with #19 S/N 336501 to 414627BOLT WHEEL 1/2-20X1 90-DEG802-104C14.
HHCS 1-8X4 GR5802-073C15.
Rev. 2TIRE & WHEEL LAM. 6X9X21(TALL)814-059C16.
Rev 1; Use up stockTIRE & WHEEL LAMINATED 6X12X19814-151C16.
Rev. 3; Not interchangeable(S/N 419602+AC TIRE 24 X 7.7 2PC814-263C17.
Rev. 2 not compat. w/Rev. 1.(S/N 328237 to 419601)AC TIRE 27x7.75x15 MOUNTED814-201C17.
Rev. 1(S/N 328236-)TIRE 25.5 X 8.0-14 - MOUNTED814-086C17.
Rev. 3; Not interchangeable(S/N 419602+)AC TIRE 24 x 7.7 2PC FOAM FILL814-262C18.
Rev. 2 not compat. w/Rev. 1.(S/N 328237 to 419601)AC TIRE 27X7.75X15 FOAM FILLED814-202C18.
Rev. 1(S/N 328236-)TIRE 25.5 X 8.0-14 - FOAM FILLED814-189C18.
WHEEL 15 X 5 X 4 BOLT814-066C19.
Rev. 2 not compat. w/Rev. 1.(S/N 419602+)WLDMT. WING AXLE LH. HAND318-583H20.
Rev. 1(S/N 223260 to 419601)WLDMT. WING AXLE LEFT HAND318-190H20.
Rev. 2 not compat. w/Rev. 1.(S/N 419602+)WLDMT. WING AXLE RH. HAND318-576H21.
Rev. 1(S/N 223260 to 419601)WLDMT. WING AXLE RT. HAND318-189H21.
(S/N 223260+)SPINDLE - SINGLE AXLE BOLT ON815-108C22.
(S/N 223260+)SPINDLE - DUAL AXLE BOLT ON815-109C22.
(S/N 223260+)HHCS 1/2-13X3 1/4 GR5802-099C23.
(S/N 223260+)NUT LOCK 1/2-13 PLT803-019C24.
Rev. 3; Not interchangeable(S/N 419602+)TIRE 24X7.7-14 (814-263C)814-266C25.
Rev. 2 not compat. w/Rev. 1.(S/N 328237 to 419601)TIRE 27X7.75-15 (814-201C)814-203C25.
Rev. 1(S/N 328236-)TIRE 25.5 X 8.0-14 (814-086C)814-087C25.
Rev. 3; Not interchangeable(S/N 419602+)TUBE FOR 24X7.7-14 (814-263C)814-268C26.
Rev. 2 not compat. w/Rev. 1.(S/N 328237 to 419601)TUBE FOR 27X7.75-15(814-201C)814-204C26.
Rev. 1(S/N 328236-)TUBE FOR 25.5X8.0-14(814-086C)814-088C26.
Rev. 3; Not interchangeable(S/N 419602+)RIM 2PC. 4BLT 10X6 BLACK814-267C27.
Rev. 2 not compat. w/Rev. 1.(S/N 328237 to 419601)RIM 2PC.4BLT 15X6 BLACK814-205C27.
Rev. 1(S/N 328236-)RIM 2PC.4BLT 14X6BLACK814-086C814-089C27.
Use with #16, 17 & 18 S/N 414628+NUT HEX FLG/LK 1/2-20 PLT.GR.G803-308C28.
Use with #19 S/N 414628+NUT LUG 1/2-20X90DEG PLT 13/16803-017C28.
(S/N 414628+)HUB STUD 1/2-20X1 5/8 GR5802-135C29.
GREASE ZERK STRAIGHT 1/4-28800-001C30.
BEARING CUP 15245822-092C31.
(S/N 419602+)BUSHING 1.25ODX1.00IDX3.50890-819C32.
02/03/09 RC5015, RCM5015, RC6015 & RCM6015 Rotary Cutters 318-047P 37
Table of Contents Part Number Index
Section 3: Axles Land Pride
RC5015 & RC6015 SERIES (540 RPM)
Axle Wing (S/N 489025-)
Applies to RC5015, RC6015
