RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg24851
ACCESS COVER PLATE312-812D1.
WLDMT. SHAFT PROTECTOR318-141H2.
WLDMT. SKID SHOE RH.318-145H3.
WLDMT. SKID SHOE LH.318-146H4.
TOP PLATE SKID REINFORCEMENT318-167D5.
TOP PLT SKID REINFRCMNT GREEN318-167D815.
TOP PLT SKID REINFRCMNT RED318-167D835.
FORMED HINGE BRACKET318-322D6.
SHIELD BRACKET WELDMENT318-401H7.
WLDMT. CENTER SECTION318-423H8.
WLDMT. CENTER SECTION GREEN18-423H818.
WLDMT. CENTER SECTION RED318-423H838.
WLDMT. CTR. SECT. DR.318-543H8.
WLDMT. CTR. SECT. DR. GREEN318-543H818.
WLDMT. CTR. SECT. DR. RED318-543H838.
WLDMT. CYLINDER SPRING BASE318-479H9.
S/N 584787+PLATE, DIV. BOX SUPPORT318-746D10.
HHCS 1/4-20X1 GR5802-005C11.
HHCS 3/8-16X1 GR5802-017C12.
S/N 584787+ & ITG Divider Box
Mount Bolt
HHCS 5/8-11X1 3/4 GR5802-053C13.
Omin Divider BoxHHCS 3/4-10X1 3/4 GR5802-392C13.
Comer Divider BoxHHCS 5/8-11X2 1/2 GR5802-058C14.
HHCS 3/4-10X2 1/4 GR5802-065C15.
HHCS 3/4-10X6 GR5802-070C16.
HHCS 1-8X5 GR5802-235C17.
HHCS M8X1.25X20 GR8.8802-314C18.
HFS 1/2-13X2 GR8802-456C19.
NUT LOCK 3/8-16 PLT803-013C20.
NUT LOCK 3/4-10 PLT803-026C21.
NUT HEX TOP LOCK 1-8 PLT803-168C22.
NUT HEX FLG. LOCK 1/2-13 PLT.803-169C23.
NUT WING 3/8-16 PLT803-231C24.
NUT HEX NYLOCK 1/4-20803-255C25.
S/N 584787+NUT HEX FLANGE LOCK 5/8-11 PLT803-263C26.
Comer Divider BoxNUT HEX TOP LOCK 5/8-11 PLT803-271C27.
NUT HEX FLG TOP LK 3/4-10 PLT803-299C28.
WASHER FLAT 1/4 SAE PLT804-007C29.
WASHER LOCK SPRING 5/16 PLT804-009C30.
WASHER FLAT 5/16 USS PLT804-010C31.
WASHER FLAT 3/8 SAE PLT804-012C32.
WASHER LOCK SPRING 3/8 PLT804-013C33.
ITG Divider BoxWASHER LOCK SPRING 5/8 PLT804-022C34.
Omni Divider BoxWASHER LOCK SPRING 3/4 PLT804-023C34.
WASHER FLAT 3/4 USS PLT804-024C35.
PIN COTTER 5/32 X 1 1/4 LG805-045C36.
PIN CLEVIS 3/8 X 5 1/2 PLT805-309C37.
SPRING HOSE LOOP807-023C38.
SPRING COMP 1.88OD x .362W807-143C39.
MANUAL STORAGE CONTAINER816-481C40.
KNOB 3/8-16 FEMALE THD 2 3/8OD817-259C41.
PLASTIC DIVIDER BOX SHIELD817-484C42.
RC5014GBOX RC60 1:1.46 CW826-321C43.
GBOX RC60 1:1.46 CW GREEN826-321C8143.
GBOX RC60 1:1.46 CW RED826-321C8343.
RCM5014GBOX RCM5014 1.21:1 CW826-547C43.
GBOX RCM5014 1.21:1 CW GREEN826-547C8143.
09/03/08 RC5014 & RCM5014 Rotary Cutters 330-117P 9
Table of Contents Part Number Index
Section 2: Decks Land Pride
Deck Center Section
Applies to RC5014, RCM5014
