RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg24859
HUB GREASE CAP200-001D1.
WLDMT. RH. AXLE318-452H2.
GREASE ZERK 1/4-28 THD FORMING800-080C3.
HHCS 1/2-13X3 1/4 GR5802-099C4.
S/N 543468+HHCS 1-8 X 4 1/2 PLT GR8802-680C5.
S/N 543467-HHCS 1-8X4 GR5802-073C5.
S/N 543468+HHCS 1-8X6 1/2 GR8802-762C6.
S/N 543467-HHCS 1-8X6 1/2 GR5802-074C6.
HUB STUD 1/2-20X1.88 GR5802-779C7.
NUT LOCK 1/2-13 PLT803-019C8.
NUT HEX SLOTTED 3/4-16803-053C9.
S/N 543468+NUT HEX FLG LOCK 1-8 GR B PLT803-258C10.
S/N 543467-HHCS 3/8-16X3 1/4 GR5802-168C10.
NUT HEX 1/2-20 X 5/8 HIGH803-310C11.
NUT HEX SIDE LOCK 1-8 PLT803-316C12.
WASHER HARDENED .81ID804-216C13.
PIN COTTER 5/32 X 1 3/4 LG805-246C14.
TIRE & WHL LAM. 6X9X21(5-BOLT)814-265C15.
WHEEL 15 X 5 X 5 BOLT814-284C16.
AC TIRE 27X7.75X15 5-BOLT814-286C17.
AC TIRE FF 27X7.75X15 5-BOLT814-287C18.
SPINDLE-DUAL BOLT-ON815-240C19.
HUB 5-BOLT W/CUPS/STUDS815-243C20.
SEAL 1.75ID CR17617816-497C21.
BRG CUP LM-67010822-020C22.
BRG CONE 1.25ID LM-67048822-021C23.
BRG CUP LM-48510822-033C24.
BRG CONE LM-48548822-034C25.
BUSHING 1.25ODX1.00IDX2.00890-771C26.
TIRE 27X7.75-15 (814-286C)814-292C27.
TUBE FOR 27X7.75-15(814-286C)814-293C28.
RIM 2PC 5BLT 15X6 BLACK814-294C29.
09/03/08 RC5014 & RCM5014 Rotary Cutters 330-117P 27
Table of Contents Part Number Index
Section 3: Axles Land Pride
Axle Wing
Applies to RC5014, RCM5014
