Preparing the Generator
Operator’s Manual 15
ENGINE OIL
Oil is a major factor affecting performance and service life.
Use 4-stroke automotive detergent oil.
Recommended Oil: Use 4-stroke motor oil that meets or
exceeds the requirements for API service classication
SJ, SL, or equivalent. Always check the API service label
on the oil container to be sure it includes the letters SJ,
SL, or equivalent.
SAE 10W-30 is recommended for general use. Other
viscosities shown in the chart may be used when the
average temperature in your area is within the indicated
range. (Fig. 1)
CAUTION: THIS ENGINE CRANKCASE IS NOT
FILLED WITH OIL AT THE FACTORY, SO BE
SURE TO FILL IT BEFORE OPERATING THE
ENGINE.
ENGINE OIL CAPACITY
To ll with oil:
1. Level the engine to ensure accurate inspection and
to prevent overlling.
2. Remove the dipstick and wipe it clean.
3. Fully insert the dipstick, then remove it to check the oil
level.
4. If the oil level is low, remove the oil ller cap, and ll to the
upper limit mark on the dipstick with the recommended
oil. (Fig. 2)
5. Reinstall the dipstick and ller cap.
NOTE: Running the engine with a low oil level can cause
engine damage.
The Oil Alert system (applicable types) will
automatically stop the engine before the oil level
falls below the safe limit. However, to avoid the
inconvenience of an unexpected shutdown, always
check the engine oil level before startup.
(Fig. 1)
(Fig. 2)
MODEL # Liters Quart Ounces
AC-G13010SE 1.5 1.6 52.5
AC-G14010HE 1.8 1.9 60.9
TEMPERATURE CHART
