Modem Card
“Battery ASM” on page 62
To remove the modem card:
1. Use a flat-bladed screwdriver to remove the screw on
the modem door.
2. Carefully release the latches on both sides of the
modem card.
3. Gently pull out the cable from the connector to
remove the modem card.
Step
Size (Quan-
tity)
Head &
Color Torque
1 M2 x 18L (1) Pan head,
black
2.0kgf-cm
Note: The screws do not separate from the modem board
cover.
68 ThinkPad 390E
